1.automatic operate process
2.durable paper cup machine
3.stainless steel shell
4.Ultrasonic bonding
Introduction of paper cup machine:
Mkk--zb series Paper Cup Machine are automatic machine with multi-working station, which has the function of photocell detection, failure alarm, counter and the advantages of humanism design, safer operation and easier maintenance.
It makes both single and double film laminating paper cups after running a whole procedure of automatic pre-printed-fan=shape-paper feeding, cup-side-body sealing ultrasonic wave ,silicon e-oil lubricating(for top curling),bottom punching, bottom pre-heating and pre-folding, main heating, bottom knurling(cool device),top curling and cup discharging.
It is an ideal equipment of making paper cups for all kings of drinks (hot and cold) disposable paper cups: paper tea cup, coffee cup, cold-beverage cup, Beer cup, ice-cream cup etc.
Model of paper cup machine:
| Company |
Shanghai Ximan Machinery Co.Ltd |
|
|||
| Model |
Mkk_zb65 |
Mkk-zb120 |
Mkk-zb160 |
Mkk-zb180 |
|
| Cup size(oz) |
2 ,4 ,4.5, 6.5 |
6 ,8, 9, 12 |
8 , 9, 12, 16 |
8 ,9,12,16 |
|
| Material |
single side membrane |
|
|||
| Mould |
one set for free |
|
|||
| Sealing machine( $ ) |
1000 |
|
|||
| Top ( mm) |
50-80 |
50-95 |
50-95 |
50-95 |
|
| Bottom (mm) |
35-70 |
35-70 |
35-70 |
35-70 |
|
| Height ( mm) |
30-60 |
50-120 |
80-150 |
100-175 |
|
| Deepth (mm) |
≤10 |
≤10 |
≤10 |
≤12 |
|
| Conicity |
4-6o |
2-8o |
2-8o |
2-8o |
|
| Productivity |
40-50psc/min |
|
|||
| Power |
5kw |
6kw |
|
||
| Voltage |
220v,380v/50--60HZ |
|
|||
| Weight (kg) |
1600 |
1900 |
|
||
| Size(mm) |
2800*1350*1760 |
2800*1350*1760 |
3000*1350*1900 |
3300*1450*2000 |
|
| Packing size(mm) |
730*600*1100 |
|
|||
| The cost of cup |
Based on the size of cup,the material used and the colour. |
|
|||
Advantages of cup paper machine:
1, Our business distribute global, we can provide resources in the talents , market , material , technical .
2, Mkk series paper cup machine can make 50-65 pes/min. The usual cup machines just only produce 40-- 45 pes/min.
3, Mkk series cup machine is more stability than the usual machine. It doesn't need to debug again once it begins to work.
4 , The price of our products is Ex—factory price.
5 , Professional engineer to give technical support.
6 , We can produce different size of the model according the client's require.
7 , we can provide the method and technology about the cost of the cup.
Note:
1.These Mkk series machines are low speed,our middle speed machines ,write this for you :60--70pes/min,price 14000--17000 ( $ ) ,80--90pes/min,price 18400--20000 ( $ ).
2.One mould for free,the Ultrasonic we can discuss.
About us:
Dongguan Maikeku industrial co., LTD is a professional refrigerant equipment manufacturer, the leader of Ice cream &frozen yogurt machine manufacturer in China.We have patent product bulking machine, meanwhile ice cream machine, ice cream powder, slush machine, ice cream display cabinets, cake showcase, ice making machine, paper cup machine, paper bowl machine, ice block machine, ice lolly machine are our main products.
| Condition: |
New
|
Place of Origin: |
Guangdong China (Mainland)
|
Brand Name: |
MKK
|
| Model Number: |
Mkk-zb120
|
Application: |
paper cup machine
|
Voltage: |
220v,380v/50,60HZ
|
| Power(W): |
5000W
|
Weight: |
1600KG
|
Dimension(L*W*H): |
2800*1350*1760mm
|
| Certification: |
CE
|
Warranty: |
one year
|
After-sales Service Provided: |
Overseas third-party support available
|
| Mould: |
one set for free
|
Cup size: |
6,8,9,12 oz
|
Sealing machine: |
1000USD
|
| Top: |
50-95mm
|
Bottom: |
35-70mm
|
Deepth: |
≤10
|
| Conicity: |
2-8o
|
Productivity: |
40-50psc/min
|
Packing size: |
730*600*1100mm
|
| The cost of cup: |
Based on the size of cup,the material used and the colour
|
