Automatic Bottle Blowing Machine,China JIAZHOU price supplier

Automatic Bottle Blowing Machine

FOB Price:Price can be negotiated

Production Capacity:8 Set/Sets per Month

Update Time:2023-05-02

Contact Supplier

Product Description

Blowing Machine
1.capacity:3000-4000BPH
2. product:PET bottle
3.automatic
4.CE/ISO9001

blowing machine

H igh intelligent :This machine can be controlled through touch screen and running status is shown on it.

High quality: Steady infrared heating system blowing and highly precise blow-mould closing system ensure quality.

High Speed:3 5000 B/h.

No Contamination: Closed production zone,good selflubrication system avoid contamination.

High Transparency: easy maintenance,absolute safety.

TYPE	Item	Unit	HY-4000
TYPE	Item	Unit	4-CAVITY
Container	Product material		PET/PE/PC/PP
	Container volume	L	0.05-2.5
	Theoretical output	Pcs/hr	≤0.75L/4000
	Perform length	mm	50-200
	Max. length of bottle	mm	320
	Preform inner diameter	mm	Φ15-60(4-cavity)
	Bottle diameter	mm	Φ35-110(4-cavity)
Molding	Max. mould plate dimension(LWH)	mm	420×640
	Max. mould thickness	mm	220
	Clamping force	KN	280
	Mould opening stroke(Adjustable)	mm	150
Air Compressor	High pressure compressor	M3/Mpa/Kw	≥1.5/3.0×2set/11KW
Air Compressor	Low pressure compressor	M3/Mpa/Kw	≥1.6/1.0×1set/7.5KW
Dryer	Air dryer	M3/Mpa	3.0/3.0
Main Machine Electricity	Power	KW	25
Main Machine Electricity	Voltage/Frequency	V/Hz	380-220/50-60Hz
Machine Size And Weight	Main machine(L×W×H)	M	3.0×1.8×1.9
	Main machine weight	T	4.2
	Conveyer(L×W×H)	M	1.4×1.1×1.85
	Conveyer weight	T	0.3
	High pressure compressor(L×W×H)	M	1.90×0.75×1.50×2sets
	Low pressure compressor(L×W×H)	M	1.85×0.70×1.50
	High pressure compressor(L×W×H)	M/Mpa	Φ0.70×2.55×/3.0
	Air dryer(L×W×H)	M	0.85×0.50×0.95
	Air filters	Kg	10×2pcs
	Safety	Auto-emergency alarm

Factory and Workshop

Office

Certificates

Transport

Place of Origin:	Jiangsu China (Mainland)	Brand Name:	JIAZHOU	Model Number:	HY-4000
Category:	Plastic Blowing Machinery	Plastic Processed:	PET,PE,PP,PVC	Application:	Bottle
Automatic:	Yes	Blow Moulding Type:	Stretch Blow Machine	Product Type:	Plastic Bottle
Supplier Location:	China(Mainland)

Other Products

BS-1 Pull Lid and Barrel Machine

QHS 1500 carbonated drink mixer

CP-24 Bottle Washing Machine

Automatic Bottle Blowing Machine

Company Profile

Name: Zhangjiagang Jiazhou Machinery Co., Ltd.

Main Products: Beverage filling machine and accessories

Business Type: Manufacturer, Trading Company

Total Employees: 51 - 100 People

Established Year: 2005

Main Markets: Domestic Market, South Asia, Africa, Eastern Europe, Eastern Asia

Address: Sanxing Decelopment

Zhangjiagang Jiazhou Machinery Co., Ltd. is located in the Yangtze River Delta. We are a professional beverage filling equipment manufacturer, specializing in beverage production and packaging complete lines, as well as various water treatment machines. As one of the earliest companies engaged in manufacturing liquid filling and packing equipment in China, our company has become an excellent manufacturer supplying various series of hi-tech production lines with advanced technology.

At present, we can provide the following complete sets of production lines:
1. 2,000-24,000b/h mineral water & pure water filling production lines
2. 2,000-24,000b/h fruit juice & fruit tea hot filling production lines
3. 2,000-20,000b/h carbonated drink filling production lines
4. 100-1200b/h 5&3 gallon barreled water filling production lines
5. 1000-8000b/h vinegar & wine filling production lines
6. Complete sets of water purify equipment
7.Turn-key projects

Our products not only sell well in domestic market, but also are exported to overseas including Canada, Mexico, Malta, Russia, Kazakhstan, Armenia, Ukraine, Philippines, Vietnam, Cambodia, India, Pakistan, Iraq, Libya, Nigeria, Tanzania, Ghana, South Africa, Zambia and Congo etc.

We would like to cooperate with clients to develop long-term steady business relationships. We look forward to hearing from you in the near future. We welcome new and old customers to contact us. more
