automatic horizontal small chocolate bar wrapping machine,China KCX price supplier

automatic horizontal small chocolate bar wrapping machine

FOB Price:Price can be negotiated

Production Capacity:35 Unit/Units per Month

Payment Terms: US $7,500 - 9,500 / Unit

Update Time:2014-09-28

Contact Supplier

Product Description

small chocolate bar wrapping machine
1.40-330bags/min
2.body material: SS304
3.stable,reliable
4.Film: OPP/POF/BOPP/PE

Automatic small chocolate wrapping machine

Specification

Type	KCX-280B	KCX-280D	KCX-280E	KCX-280S
Film width(mm)	Max.280mm		Max.210
Bag length(mm)	65-190, 120-280	90-220, 150-330	45-90
Bag width(mm)	30-110		55-110	45-95
Product height(mm)	Max.40	Max.55	Max.35	Max.40
Film roll diameter(mm)	Max.320
Speed(bag/min)	40-230		60-330
Power	220v, 50/60hz 2.4kw
Machine size(mm)	*37706701450*
Machine weight(kg)	700
Remarks	With Date Printer

Application

Used for solid objects or things with pallet, such as Food, daily necessities, chemical, medicine and hardware, etc.

Introduction

KCX type machine has wide use range and stable characters. This type machine can achieve to wrap several kinds of products on one machine and it is a machine with high running speed.

In this case there is a high request for the machine’s strength and stability or the machine life will be reduced and the packing precision is lower due to long time running.

Features

1. PLC control.
2. Display the packaging speed and length automatically, insuring cut-off accuracy.
3. AC motor attached with converter, realizing the step-less control, dynamic adjustment in operation.
4. Photo-detection and dual tracking, which are capable of eliminating packaging error effectively and preventing material waste.
5. New type vertical seal heating, can seal at a low temperature and avoid burning film effectively.
6. Adjustable bag former, between fork spreader settings, which are convenient for changing products.

Type:	Wrapping Machine,Packing Machine	Condition:	New	Application:	Food
Packaging Type:	Bags	Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	220V	Power:	2.4KW
Place of Origin:	Shandong China (Mainland)	Brand Name:	KCX	Model Number:	KCX-280B
After-sales Service Provided:	Engineers available to service machinery overseas	Max.Film Width:	280mm	Film:	OPP/POF/BOPP/PE
Dimensions(mm):	37706701450

Company Profile

Name: Qingdao Kunchengxiang Machine Factory

Main Products: Packing Machine,chocolate wrapping machine,candy packaging machine,soap packing machine,food packing machine

Business Type: Manufacturer, Trading Company

Total Employees: 301 - 500 People

Established Year: 1999

Main Markets: Eastern Asia, Mid East, Southeast Asia, South America, North America

Address: No.1205,Block B, the Junction of Hanghai and Xinghua Road

Qingdao Kunchengxiang Machine Factory is specialized in developing and producing packing machines and forging pressing machines.

We have a strong technical team and an experienced production and QC team. We comply with ISO2001:9000 quality management system standard and some machines have gotten CE certificate. Our packing machines have occupied 80% of domestic market share and have been exported to over 20 countries and regions, such as Europe, America, the Middle East and Southeast Asia. Our forging press machines have been exported to India, Vietnam, Bangladesh and Congo and gained good feedback from our customers.

If you are interested in any of our products, or hope to place a customized order, please contact us. We will do our best to meet your needs and guarantee stable and timely supply, credible quality and sincere and professional service. more
