Applications:
It is suitable for automatically packaging of viscous products with free-flowing such as tomato sauce lotion noodle jam, edible oil ,meat jam and broth The processes of bag making measuring, filling, sealing, counting and hot pressing codes can be done automatically Packing material include several kinds of heat-seal lamination, such as PET/plated AL/PE,PET/PE,NYLON .....etc.
Features:
1. All stainless steel cover meets to GMP standard. 2. The machine is suitable for hot sealing and assembling attemperator depend on customer's requirement. 3. Automatic adjustment of pouch size and filling range. 4. Automatic self-support lubricating system, the machine can work 24 hours. 5. The operation facility is controlled by American intel computer, all function is displayed with digital screen. 6. Minimum sealing temperature variation employs PID temperature, the tolerance is controlled by ±2%. 7. The machine can be equipped with a product stirrer and heated jacket for high temperature product packaging. 8. Ink printer and conveyor are as an option.
|
DXDJ-40II
|
DXDJ-150II
|
Bag size
|
(L) 55
|
(L) 70
|
Capacity
|
40-85 bags/min |
35-60 bags/min |
Filling range
|
5-40 (ml)
|
30-150 (ml)
|
Power
|
220V 50HZ 1.5KW
|
220V 50HZ 1.9KW
|
Weight
|
350 (kg)
|
450 (kg)
|
Dimension L * W * H |
600X 790X1780 (mm3)
|
700X 800X1900 (mm3)
|
Established in 1986, the corporation is specialized in producing various packaging machine and food machine…etc. As a manufacture HONDON PACKAGING MACHINERY GROUP have aware of providing high quality machines and consummate service are most essential part. Aim at focusing on the customer and serving the economic market, HONDON gradually implement diversified policy, producing and exporting all kinds of optimized and delicate packing such as PET/ AL/PE, BOPP/PE, PET/VMPET/PE and TEA-LEAF FILTER PAPER.
With over than 20 years of experience in this field , we deserved “ISO9001:2000” and we were the first manufacture to obtain “Europe Counties Quality Certificate of CE system” for all packing machines we produced, and we gain confidence of our customers over 40 countries around the glob , such as U.S.A., Canada, Egypt, Turkey, Iran , Russia, Malaysia.
Manufacturing of wide range of packaging machinery, our core production strength lies in the high quality raw material such as all stainless steel, famous branded electronic devices (Omron, Siemens, Fuji, and Mitsubishi).
Attention to detail, professional service, distinguished quality products and going the extra mile for our customers are the hallmark of HONDON. Supported from own manufacturing plants and R&D center, through troubleshooting department, HONDON can assure a strict quality control check of components before assembly, guaranteeing highly performing and long-lasting machines.HONDON’s role does not end once the final packaging machine has been determined but to provide a integrated service from original select to final after sales service for developing a long-term business relationship by ensuring customer satisfaction, discerning their need, and delivering our promise at the same time maintaining the core service value in our heart. Fast and easy shipment channel are available from manufacturing plants in China to destination ports all around the world at high competitive rates, supported by excellent infrastructure and shipment schedule are never delay.
The successful growth of HONDON could never have been achieved without the support and co-operation of the companies who put their trust in our products. We owe a debt of gratitude to those companies and offer the promise of our continuing service and bold support to them.
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
