Automatic Tea bags packing machines with outer bag
A. Application:
The machine is suitable for the dual bag packing of small grain-like materials, such as tea leafs, medicinal tea and healthy teas.
B. Features:
Controlled by a step motor, the outer seal has a fixed length and a correct position.
PID is used to adjust the temperature controller for more accurate temperature control
PLC is used to control the motion of the whole machine, with a human-machine interface display and easy operation
All touchable material parts are made of SUS304 stainless steel to ensure sanitary and reliable products
Some of the working cylinders use OEM parts to ensure steady and accurate performance
The attached device has functions including cutting, Date printing and easy tearing.
C. Parameter
Features: the inner bag can be with and without string and tag
Dosage range: 1-15g/bag
Packing speed: 40-75bag/min
Inner bag size: W: 40-80mm, L: 50-80mm
Outer bag size: W: 60-90mm, L:70-90mm
Tag size: W: 25-55mm, L: 20-40mm
Thread length: 155mm, 210mm
Power supply: 220/380V, 50-60Hz( can be customized accordingly)
Total power: 3.5Kw
Machine dimension: 950x850x1850mm
Machine weight: 500KG
Beta Packaging Machinery, CO., Ltd, once called Yujie packaging machinery, which is founded in 1995, lies in the beautiful city ,Xiamen, is a professional manufacturer of a wide array of packaging machinery and packing system for decades. Better quality and dedicated after sale service has won a high reputation among worldwide customers
With decades development, We has successfully developed many kinds of bag form, fill and seal machine such as:
1)tea bag packaging machinery ; 2) granule packaging machinery
3) Powder packaging machinery ; 4) Liquid/paste packaging machinery
5) Snack food packaging machinery;
Except facilitated with one innovative R&D team, Beta also has 6 professional assembly line, one professional after sale service team and has successfully work out a strict quality management system.
"Quality as the foundations, customer’s satisfaction as the orientation, we always pursue better packaging solutions"
Live by quality, develop by prestige!
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
