bubble chewing gum kneader mixer,China JCT price supplier

bubble chewing gum kneader mixer

FOB Price:Price can be negotiated

Production Capacity:20 Set/Sets per Month

Payment Terms: US $1,900 - 290,000 / Set

Update Time:2014-09-25

Contact Supplier

Product Description

1)bubble Chewing Gum kneader Mixer
2)jacket heating
3)Kneading,dispersing,mixer.
4)Viscos Mixer.
5)Melting mixer.

dispersion & kneader mixer

CHARACTER:

1) Chew Gum Kneader including the normal pressure, high pressure and vacuum type.

2) Temperature adjustment: heated by oil, steam or electricity, cooled by water.

3) Discharge method: tilt dump, bottom dump and screw discharge.

4) The seal of shaft agitator is adopted with unique balance construction of vacuum box, Which owns patent.

5) The cover is controlled by hydraulic system.

CONSTRUCTION TO THE MIXER:

TECHNICAL PARAMETERS:

Model	Cylinder volum(L)		Drive motor power (KW)	Stirring speed (rpm)	Discharge mode			Heating
Model	Full volume	Feeding amount	Drive motor power (KW)	Paddle fast / slow paddle
NHZ5	5	3	2.2-4	75/50	Turn cylinder			Hot oil	Power	Steam
NHZ20	20	12	3-5.5	63/42	Turn cylinder
NHZ50	50	30	4-7.5	63/42	Turn cylinder
NHZ100	100	60	5.5-7.5	43/29	Turn cylinder
NHZ200	200	120	7.5-15	43/29	Turn cylinder	The material under	Screw the material
NHZ300	300	180	11-18.5	43/29
NHZ500	500	300	18.5-30	43/29
NHZ1000	1000	600	22-55	32/22
NHZ1500	1500	900	30-90	32/22
NHZ2000	2000	1200	45-110	32/22
Remarks: 1,Temperature range: 0-300° 2, Pressure range:-0.1-0.6MPa

We do strongly recommend the Euro & Chinese brand parts, If choose Japan bran the quote price will be 50% more.

Condition:	New	Mixer Type:	Paddle	Product Type:	rubber
Application:	Liquid	Additional Capabilities:	Coating	Place of Origin:	Guangdong China (Mainland)
Brand Name:	JCT	Model Number:	NHZ-1000L	Max. Loading Capacity:	600L
Voltage:	380V	Power(W):	45kw	Dimension(LWH):	250015004900
Certification:	CE	Warranty:	1 year	After-sales Service Provided:	Engineers available to service machinery overseas
Heating:	0-300 °C	Vacuum:	-0.096Mpa	discharge method:	bottom discharge
Speed:	Adjustable	Cooling:	Water Cooling	Control:	PLC Control
Sensor:	PT100	Usage:	Sticky Material	Material:	SUS304 Stainless
