chocolate bean forming Machine,China YOKE price supplier

  chocolate bean forming Machine ( Model: TQCJ400)

(include one set of cold roller and cooling tunnel)

Use:

The product is a piece of special equipment for chocolate bean forming, which is used for pure chocolate of different shapes in cold rolling, including shapes such as ball, egg, star, heart, triangle and so on.

Main technical parameters:

Production capability: 1,500kg/8hours

Roller dimension: 414(diameter)*400(length)mm

Roller motor power: 1.1kw

Temperature of the cooling tunnel: 0 ~ 5 °C

Length of the cooling tunnel: 6metres * 3 layers

PU conveyor width: 600mm

Cooling tunnel match one 8HP cooling compressor, motor power: 1.1kw

Refrigeration quantity of the cooling liquid: 6280W (evaporation temperature-30 °C , condensing temperature 30 °C )

Motor power of refrigeration and cooling system: 10HP

Power of the machine: 21.3KW

Dimensions:7220×1040×1840 ( L×W×H )

Weight of the machine: 2400kg
