chocolate machine to produce chocolate bar,China JY price supplier

chocolate machine to produce chocolate bar

FOB Price:Price can be negotiated

Production Capacity:100 Set/Sets per Month

Payment Terms: US $10,000 - 100,000 / Set

Update Time:2014-09-28

Contact Supplier

Product Description

ISO&CE certificate,Chocolate packing machine factory, chocolate packing machine manufacturer,we can design based on your demand

chocolate production line:

Detailed description of necessary machines and technical parameters:

1. Cocoa butter Melting Tank

The cocoa butter melting tank is used for melting the cocoa butter. This tank could be heated by the electrical immersion heater. The tank wears hot-water jacket.

Capacity:	360kg
Motor power:	8kw
Shape:	Rectangle or cylinder
Material:	Inner: stainless steel, outer: mild steel
Outside dimension:	19009701250mm

2. Sugar grinding machine:

USE:

The sugar grinding machine is a kind of chocolate machine mainly used for secondary grinding of granulated sugar.

Production capacity:	250kg/h
Feeding granularity:	0.5~2mm
Average grain:	80-100 mesh
Main shaft power:	7.5kw
Feed motor power:	1.5kw
Main shaft Rotation speed:	3800r/min
Feed spindle rotation speed:	217r/min
Net weight:	500kg
Gross weight:	720kg
Outside dimension	12409601733mm

3. Chocolate conche machine:

USE:

1).The chocolate conche machine is one of the major chocolate machine in the chocolate production line which are used for the fine grinding of chocolate material.

2).The fine grinding time is about 14~20 hours, the average granularity can achieve 20μm.

3).This chocolate machine has many merits such as tight structure, easy operation, convenient maintenance, few one-off investment, and so on.

4).It is suitable especially for the technical request of medium chocolate and candy factory.

Model/Project:	1000L
Maximum capacity(L):	1000L
Grinding Fineness(micron):	20~25
Main Axle Rotating Speed(rpm):	35
Grinding time(h):	16~22
Main motor power(kw):	18.5
Electrical heating power(kw):	2*2
Weight(kg):	3050
Outside dimensions(mm):	262712801520

4. Chocolate holding tank

USE:

The chocolate holding tank is a necessary equipment in chocolate production line. It wears double warm-water jacket which used for temperature storage of fine ground chocolate paste.So that to meet the technical request of chocolate production and the request of continuous production.

This chocolate tank has functions of temperature decrease, rise and preservation.

Besides it has the functions of degasification, desmelling, dehydration and preventing the chocolate paste from the separation of oil and grease and so on.

Model:	JY1000
Maximum capacity	1000kg
Motor power:	2.2kw
Stirring Rotational Speed:	24 rpm
Whisk Rotational Direction:	Clockwise (Viewed from above)
Electric Heater Power:	4kw
Tank Interlayer Water Temperature:	55°C (Warm-up temperature of chocolate mass)
Net weight:	1000kg
Outside dimension:	(Diameter)1220*(Height)1850mm

5. Chocolate depositing machine:

USE:

1).This chocolate depositing line can produce pure solid chocolate, center filling chocolate, two color chocolate, nuts mixed chocolate with nuts mixing machine. Chocolate can be compound chocolate and real chocolate.

2).Products can be manufactured with biscuits or wafers simply by installing the relevant biscuit feeding units.

3).Chocolate depositing line can complete automatic feeding mould, baking mould, depositing, vibrating mould, cooling, de-moulding, conveying empty moulds for cycle AUTOMATICALLY and dosage system is mechanical.

4).This depositing line has merits of high productivity, accurate dosing, smooth surface of chocolate etc.

5).Meet the requirement of international food sanitation standard.

Production capacity:	800 - 2500kg/shift
Depositing times:	20 - 25times/minute
Dosage system:	mechanical
Mechanical vibrating frequency:	200 - 1000times/minute.
Molds vibrating amplitude:	0 - 3mm, adjustable
Cooling time:	18 - 30min
Cooling temperature:	5 - 10°C
Cooling tunnel length:	8.2m * 8 Layers
Time of baking molds:	20 - 36 seconds
Temperature of baking molds:	35 - 40°C
Length of baking molds:	1.4m
Refrigeration capacity:	20000 - 25000kcal/h (10 HP COPERLAND)
Evaporator area:	80 square meters
Quantity of moulds:	300 pieces
Dimension of moulds:	standard 275×175×30mm
Total Power of machine:	17.4kw
Dimensions:	16000×1000×1800(L×W×H, mm)
Weight of the machine:	3500kg

6. Pumps:

Motor power	1.5/0.75kw
Rotation of main spindle	127r/min
Maximum flow	32/25L/min
Mass viscosity	2m
Maximum delivery lift	50°E35
Weight	120/80kg
Dimension	820×390×350

Customers and Certificates:

Condition:	New	Place of Origin:	Shanghai China (Mainland)	Brand Name:	JY
Model Number:	175-1	Application:	Chocolate	Voltage:	380V/220V
Power(W):	22KW	Weight:	3600kg	Dimension(LWH):	262712801520
Certification:	ISO &CE	Warranty:	one year	After-sales Service Provided:	Engineers available to service machinery overseas
material::	stainless steel
