Food online > Products > Food Ingredients > Cocoa Ingredients >

cocoa powder packing machine,China Jie Swisu price supplier

cocoa powder packing machine

FOB Price:Price can be negotiated

Production Capacity:100 Set/Sets per Month

Payment Terms: US $3,000 - 5,000 / Set

Update Time:2014-09-20

Contact Supplier

Product Description

Alibaba china Sugar automatic granule packing machine
1.PLC control
2.high filling accuracy
3.CE certificate
4.factory sell

Alibaba china sugar automatic granule packing machine

CJXH-FT08

Sugar automatic granule packing machine
Sealing types: 3-side sealing, 4-side sealing, back sealing, stick sealing
It is flexible enough for automatically packing, widely used in sugar, coffe, Milk granule packing etc.
PLC control with stable reliable biaxial high accuracy output and color touch screen, bag-making, measuring, filling, printing,cutting, finished in one operation.
Adjustment of bag deviation just needed to be controled by the touch screen. Operation is very simple. Close down type mechanism , defending powder into inside of machine.

Model	filling range	filling speed
CJFT-10	5g-100g	100 pcs/min
CJFT-50	100g-500g	70 pcs/min
CJFT-100	500g-1000g	50 pcs/min
CJFT-500	1000g-5000g	30 pcs/min

Model	CJXH-FT08
Type	granule packing machine
Packaging speed(5000g)	70 sachets/min
Sachet dimension	length: 60---300mm
	width: 60---200mm
Maximum width of film	420mm
Thickness of rolling film	0.04-0.09mm
Feeding film type	Single belt
Air consumption	0.8Mpa 0.5m3/min
Supply power	3KW 220V 50HZ
Machine dimension	L1260 x W1015 xH1560mm
weight	450kg

The machine is made of stainless steel, please be careful when cleaning surface of machine. Do not use sharp tool to scrape the surface of machine.
Could choose alcohol to clean blot of machine surface.
The cylinder has been filled with lube oil before leaving factory, so please don’t take apart the cylinder to fill lube oil.
Hopper, stainless steel three-way valve and three-way conversion valve could take apart to clean. The seal ring should change in time.

→ → → What is your packing style???

Any more details, just tell me!

Type:	Other,granule oacking	Condition:	New	Application:	Food,Beverage,Commodity,Medical,Chemical,Machinery & Hardware,Apparel,Textiles,sugar
Packaging Type:	Cartons,Cans,Bottles,Barrel,Stand-up Pouch,Bags,Film,Foil,Belt,Pouch,Capsule,Case,sachet	Packaging Material:	Plastic,Paper,Metal,Glass,Wood	Automatic Grade:	Automatic
Driven Type:	Pneumatic	Voltage:	220V / 380V / 110V	Power:	3KW
Place of Origin:	Hubei China (Mainland)	Brand Name:	Jie Swisu	Model Number:	CJXH-FT08
Weight:	180KG	Dimension(LWH):	126010151560mm	Certification:	ISO CE CO
After-sales Service Provided:	Engineers available to service machinery overseas	name:	sugar automatic granule packing machine	material:	stainless steel
packing weight:	100-5000g	guarantee:	1 year but long life service	filling speed:	30-70 sachet/min
feeding film type:	single belt	sealing type:	3-side 4-side stick back	quality:	high quality
sensor:	Omron

Company Profile

Name: Wuhan Jie Swisu Mechanical & Electrical Co., Ltd.

Main Products: Aerosol filling machine,liquid filling machine,powder packing machine,paste filling machine,Automatic liquid packing machine

Business Type: Manufacturer, Trading Company

Total Employees: 51 - 100 People

Established Year: 2003

Main Markets: Domestic Market, South America, Southeast Asia, Oceania, Western Europe

Address: No.1 SBIChuangYe Street, optical valley East-Lake Hi-Tech Development Zone

Wuhan Jie Swisu Mechanical & Electrical co.ltd was founded in 1995, with 17 years experience in developing and manufacturing chemical machinery.

"Relying on science and technology for development,and providing customers with high--tech product " is our constant pursuit.

In the full introduction of advanced technology ,we have gradually accumulated powerful technical forces ,advanced production facilities, perfect testing means and optical after sales service.

"Chaojie" is our service brand. Currently, our company mainly produce chemical machinery equipments ,such as aerosol filling machine ,paste filling machine, liquid filling machine , washing power equipment ,detergent equipment. We have won high reputations in the field .Our products have already been passed through strict inspection to all industries are under nomal operation. Our products enjoy good sales in the whole nation ,as well as in the Middle East, Africa, Southeast Asia and Europe.

Our company pursues the strategy of "brand strategy, high quality product strategy" . We adhere to the "full service for customer ,brand promotion "and the quality policy of "sincere service and technical solutions "

We also sincerely welcome old and new customers from at home and abroad to visit us and negotiate business with us ! more
