cocoa powder pulverizer machine

FOB Price:Price can be negotiated

Production Capacity:30 Set/Sets per Month

Payment Terms: US $14,000 / Set

Update Time:2021-10-04

Contact Supplier

Product Description

1 COCOA POWDER pulverizer machine
2 stainless steel 304
3 water cooling
4 80-320 mesh

Working Method:

The material enters the grinding chamber via the funnel and spiral Conveyor where it is sheared and broken by the fastrotating blades.

The power passes the guide ring and enters the classification chamber.

As the classification wheel is in revolution, both the air force and centrifugal force act on the powder.

As the particles whose diameters are greater than the critical diameter (diameter of the classification particles) have a great mass, they are thrown back into the grinding chamber to be ground again, while the particles whose diameters are smaller than the critical diameter enter the cyclone separator and bagtype collector via the material exit pipe be means of negative pressure wind conveyance.

The discharge material meets the requirement for the product.

Model	JB-15	JB-20
Capacity (kg/h)	10-200	10-300
Size of input granules(mm)	<10	<10
Size of output granules (mesh)	80-320	80-320
Power (kw)	13.5	20
Speed of principal axis (rpm)	~6000	~5400
Overall size (LWH)(mm)	420012002700	550014003000
Weight ( kg )	950	1250
Material	SS304	SS304

Model	JB-30	JB-60	JB-80	JB-100
Capacity	30-800	50-1200	100-1500	200-2000
Size of input granules (mm)	<15	<15	<15	<15
Size of output granules (mesh)	80-320	80-300	80-320	80-320
Power (kw)	46	84	121	183
Speed of principle axis (rpm)	~3800	~2800	~2400	~2000
Overall size(LWH) (mm)	780018003900	950022004500	950022004500	1100023005100
Weight (kg)	2000	4200	5600	7500
Material	SS304	SS304	SS304	SS304

Production line

CE of JB icing Sugar mill

Condition:	New	Place of Origin:	Jiangsu China (Mainland)	Brand Name:	Jinbao
Model Number:	30/60/80/100	Usage:	Sugar	Type:	Sugar Mill
Voltage:	All countries are OK	Power(W):	84	Weight:	4200 kg
Dimension(LWH):	950022004500	Certification:	CE ISO	Warranty:	1 year
After-sales Service Provided:	Engineers available to service machinery overseas	Material:	stainless steel	MOQ:	1 set
Price:	14000 USD
