commercial spice Grinder
1.stainless steel spice grinder
2.multifunctional
3.dust removal and water cooling
4.CE.ISO
Compact structure!!! Commercial Spice Grinder/Spice Grinder
Main application of Commercial Spice Grinder:
1.Grain flour Mill for variety of food sesame seeds, walnuts, rice, black rice, soybeans, mung beans, peanuts, seeds, corn, sorghum, barley, buckwheat, oats, etc.
2.Grain Flour Mill for kinds of dry herbs: almonds, Poria, dates, Gorgon, Wolfberry , barley, hawthorn, Chinese yam, Radix, red beans, gelatin, frankincense, dodder seed, angelica, Codonopsis, Astragalus .
Advantages of Commercial Spice Grinder:
1.Grain Flour Mill structure is simple and strong, stable running, crushing the material fast, uniform, effect is good.
2.Grain Flour Mill change the ordinary grinder wall roughness, easy, difficult to clean up the phenomenon of accumulated powder, the production of food, medicine, chemical industry and so on can meet the national standards, meet GMP requirement.
Working principle of 20-40Kg/h Commercial Spice Grinder :
1.Working prin ciple of the high quality stainless steel, 304 national standard motor, mainly used in chemical materials, Chinese herbal medicine containing the roots, branches and block class materials, all kinds of food, grain oil content is not high, and other hard and brittle materials .
2.The Grain Flour Mill using the disk activity and fixed means of relatively high-speed operation, make the shattered by the gear disk impact, friction and collision among the materials themselves and crushed. Material can be directly from the eduction in the grinding cavity, the discharging mouth, the general material after crushed through cotton bags to collect, shredded material collected in the bag, air from a bag of tiny hole to come out, will not be fine powder, thereby no waste, no pollution effect. By changing sieve in different mesh size.
Technical Parameters of Commercial Spice Grinder:
MODEL |
CAPACITY (kg/h) |
FINENESS ( MESH ) |
VOLTAGE (v) |
POWER (kw) |
Rotate speed |
dimentions (mm) |
weight (kg) |
FR -180 |
30-120 |
10-120 |
220/380 |
2.2 |
4200 |
480*520*1040 |
80 |
FR -250 |
60-200 |
10-120 |
380 |
5.5 |
4200 |
750*600*1260 |
180 |
FR -320 |
80-300 |
10-120 |
380 |
7.5 |
4200 |
780 *700*1350 |
260 |
FR -350 |
100-500 |
10-120 |
380 |
11 |
4200 |
800 *900*1550 |
320 |
FR -450 |
500-1000 |
10-120 |
380 |
15/22 |
4200 |
1200*1000*2000 |
520 |
Machine models:
Production effect :
Find your mandy:
Place of Origin: |
Henan China (Mainland)
|
Brand Name: |
Furui brand commercial spice grinder
|
Model Number: |
FR-180 Grain Flour Mill
|
Type: |
spice grinding machine,Commercial Spice Grinder
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Capacity: |
30-120 kg/h
|
Power: |
2.2 kw
|
Dimension: |
480*520*1040 mm
|
Fineness: |
10-200 meshes
|
Speed: |
4200 r/min
|
Material: |
stainless steel 304
|
Voltage: |
220v/380v (can change it for your need)
|
Weight: |
80 kg
|
Mission: |
Professional and good service
|
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
