fruit grading machine,China genyond price supplier

fruit grading machine
FOB Price:Price can be negotiated
Production Capacity:100 Set/Sets per Week
Payment Terms: US $4,000 - 20,000 / Set
Update Time:2021-07-21
Product Description

fruit grading machine
1.stainless steel
2.easy to operate
3.high quality and efficiency
4.low price

Working principle of mango fruit grading machine

Machine consists of frame, reducer, reducer casing, sprocket cover, Conveyor chains, roll bars, a hopper, tighten the screw, tighten the baffle, drive shaft, driven shaft, driven sprocket, active sprocket, reducer sprocket components. After the material into the machine, under the action of gravity, the raw material self monolayer paved surface of the roller bar and kept in contact, due to the rolling of the staves, and the following non-metallic tracks, so that the roller bar in the revolution (horizontal movement) while also working surface for the same direction of rotation, the material that is in constant rotation, to the material is moved to the next process operatives can be substandard fruits and Vegetables in the material movement during detection, in order to guarantee the quality of the fruits and vegetables. The machine can also be bad fruit belt conveyor program according to the user's requirements for the design of transport.



Main technical parameter of mango fruit grading machine

 Model

 Capacity(T/h)

 Power(KW)

 Dimension(mm)

 GY-20

15-20

 1.1

 8000×1400×900

   GY -10

 8-10

 0.75

 6000×1000×900

GY -5

 4-6

 0.55

 4000×850×900

  GY -3

 1-3

 0.55

 3000×700×900

fruit grading machine fruit grading machine

Condition:
New
Place of Origin:
Shanghai China (Mainland)
Brand Name:
genyond
Model Number:
GY-100
Type:
Sorter
Voltage:
110/220/360
Power(W):
1KW
Weight:
350KG
Dimension(L*W*H):
5X1X1.3M
Warranty:
1 YEAR
After-sales Service Provided:
Engineers available to service machinery overseas
