fruit juice pasteurizer,China Xiongwang price supplier

fruit juice pasteurizer

FOB Price:Price can be negotiated

Production Capacity:10000 Piece/Pieces per Year

Payment Terms: US $3,000 - 100,000 / Piece

Update Time:2014-09-19

Contact Supplier

Product Description

FRUIT JUICE pasteurizer
1.Used for pasteurization of milk, juice and ice cream
2.The temperature can be set

fruit juice pasteurizer

The host of automatic tube sterilizer of Fresh Fruit juice is tube type high temperature sterilizer. The machine has characteristics such as compact structure, effective Sterilization, convenient operation, wide adaptation, low cost and so on. According to users’ needs, it can be supplied separately UHT sterilization system, including tube-type sterilizing machine, preheating tank, and insulation tank, the homogenizer interfaces can prevent formatting milk stone, with the pasteurization function. It can also available the entire unit, including UHT sterilizing system and flash degassing system.

Main Configuration of Tube Sterilizer

This unit is mainly composed of material system, high temperature hot water system, degassing system (optional), high pressure homogenization system(optional),CIP system, self-sterilizing aseptic system(optional) and control system and other system components.

Technical Parameters of Tube Sterilizer

Process parameters:25°C→105°C(10S)→90°C→40°C return

Cooling water:1:2(≤30°C)

Model	Capacity (t/h)	Consumption of steam (kg/h)	Pressure of steam (bar)	Electric power (kw)	Body size (L×W×H)	Weight (kg)	Tube diameter(Φ)
Model	Capacity (t/h)	Consumption of steam (kg/h)	Pressure of steam (bar)	Electric power (kw)	Body size (L×W×H)	Weight (kg)	Material	Steam	Medium
HE-UHT-XGZ-1	1	130	2.5	1.9	3.3×1.6×2.0	1490	25	DN25	25
HE-UHT-XGZ-2	2	260	2.5	2.1	3.5×1.6×2.0	1590	25	DN32	25
HE-UHT-XGZ-3	3	390	2.5	3.0	3.5×1.8×2.0	1630	38	DN40	38
HE-UHT-XGZ-4	4	520	2.5	3.0	3.5×1.8×2.0	1870	38	DN40	38
HE-UHT-XGZ-5	5	650	2.5	3.0	3.5×1.8×2.0	2060	38	DN50	38
HE-UHT-XGZ-6	6	780	2.5	3.0	3.5×1.8×2.0	2250	51	DN50	51
HE-UHT-XGZ-8	8	1040	2.5	3.7	4.5×2.0×2.0	2500	51	DN65	51
HE-UHT-XGZ-10	10	1300	2.5	5.2	4.5×2.0×2.0	2800	51	DN80	51
HE-UHT-XGZ-15	15	1950	2.5	7.0	6.5×2.0×2.2	3500	63	DN80	63
HE-UHT-XGZ-20	20	2600	2.5	11.0	6.5×2.0×2.2	4300	63	DN100	63

Condition:	New	Place of Origin:	Jiangsu China (Mainland)	Brand Name:	Xiongwang
Model Number:	HE-UHT-XGZ	Usage:	Juice	Voltage:	380V/50HZ, customizable
Power(W):	according to different models of machine	Weight:	according to different models of machine	Dimension(LWH):	according to different models of machine
Certification:	CE/ISO	Warranty:	one year	After-sales Service Provided:	Engineers available to service machinery overseas
Brands of Electric Parts:	SIEMENS, MITSUBISHI, etc.

Company Profile

Name: Zhangjiagang Baixiong Beverage Machinery Co., Ltd.

Main Products: beverage machine,water treatment machine,unscrambler,Drink mixer

Business Type: Manufacturer, Trading Company

Total Employees: 51 - 100 People

Established Year: 2000

Main Markets: North America, South America, Eastern Europe, Southeast Asia, Africa

Address: Sanxing Non-governmental Business Developing Zone, Zhangjiagang City, Jiangsu Province, China

Zhangjiagang Baixiong Beverage Machinery Co., Ltd. is located in the Yangtze River Delta, only one hour's driving time from prosperous Shanghai City. Thus, the water and land transportation is very convenient for us to offer timely delivery.

We focus on scientific research, design, manufacturing and after-sale services, specializing in producing beverage machinery, water treatment equipments.

We sincerely provide customers with various types of whole-set production lines for the filling and capping of purified water, mineral water, aerated beverage, fruit juice and wine bottles.
We adhere to the tenet of "the market as our orientation, science and technology as the leading role, services as the warranty, and integrity as the cornerstone". Meanwhile, we firmly hold to the ideal that "today's quality is tomorrow's market", and strive to win our customers' trust.

Our products have been sold to clients in 20 provinces, cities and autonomous regions around China. Furthermore, we have also exported to South Korea, Saudi Arabia, Jordan, Turkey, New Zealand, Russia, Mexico, Pakistan and Ghana.

Welcome all customers, old and new, to contact us for more details, we look forward to hearing from you in the near future. more
