Quick Detail:
1.Toshiba brand CCD sensor in top quality
2.Super wide chute to achieve high output and precision
3.Double sides cameras to ensure perfect image
4.Two rowed LED light source
5.Super 10 inch color touch screen
6.Automatic Operation
1.Widely chute , positioned each channel matched one vale correctly ,ejecting the discolor one to the defect chamber, and good materials slide down into the finished chamber .
2. The hardware system architecture of chip is ARM+FPGA, become the super brain of color sorter to operate
the program data.
3. Cutting-edge double row LED light source equipment with cooling system is more
Stable and long service life.
4. The operation interface adopts the 10-inch TFT color touch screen with multi-language, you can change the language the easily.
5.You operate the machine just only by the program setting of the compute,not by hands it
is easy to operate.
6.Japan TOSHIBA brand CCD sensor is top quality and excellent ability to treat the image.
We are the first to apply true color of three primary colors on CCD. It can identify tiny spots smaller than 0.02 mm2.
Applications:
Applicable to all types of materials,rice, grain,and industrial granules etc.
Model |
JT-CCDR2 |
JT-CCDR3 |
JT-CCDR4 |
JT-CCDR5 |
Throughput(T/H) |
1.0-2.5 |
1.5- 4.5 |
2.5-6.0 |
3.0-7.0 |
Sorting Accuracy(%) |
≥99.99% |
≥99.99% |
≥99.99% |
≥99.99% |
Optimized carryover |
≥8:1 |
≥8:1 |
≥8:1 |
≥8:1 |
Voltage(V) |
AC220V,50HZ |
AC220V,50HZ |
AC220V,50HZ |
AC220V,50HZ |
Power(KW) |
0.8-2.0 |
1.0-2.5 |
1.2 - 3.0 |
1.4- 3.5 |
Air Pressure(Mpa) |
≥0.6 |
≥0.6 |
≥0.6 |
≥0.6 |
Air Consumption(L/min) |
800-1300 |
1000-1800 |
1200-2500 |
1500-3000 |
Weight(Kg) |
700kg |
900kg |
1100kg |
1300kg |
Dimension(mm) L×W×H |
1674 *1520 *1800 |
1674 *1520 *1800 |
1983*1520*1800 |
2319*1520*1800 |
Why to choose us :
1.The success introduction of the JT-CCD color sorter into the market meets the demand of the international market.
2.Our Machine widely used among Chinese Rice and grains mill and have a good reputation.
3.Jietai band CCD color sorting machine has extended throughout over thirty countries and regions in Asia,
North America,Europe,Latin America,Australia, Africa and the middle East.
4.Can competative with Buhler’s brand quality but in more reasonable price
Commercial terms:
Minimum Order Quantity: |
1set |
Price: |
negotiation |
Packaging Details: |
wooden case |
Delivery Time: |
10 days after receive deposit |
Payment Terms: |
T/T , L/C |
Supply Ability: |
120Sets/month |
Color Sorting Machine, Color Sorter,CCD Sorter Machine.
We,Anhui Jietai Intelligent Technology, are a professional manufacture who is specified in color sorter research, production and sale, located in high-tech district hefei anhui china.
Our company originate from Thailand, which has nearly 10 years of mature experience of the grain processing, machinery production, research design and installation....
Prompt service to all the users, strive to industry greats."the good faith-based and best quality, the service quality and wordwide reputation" is our vision. "wherever the product, fast service everywhere" is the idea of our service. Jietai look forward to work with new and old friends to build a long trem coooperation and win-win relationship.
