hard candy processing line,China price supplier

hard candy processing line

FOB Price:Price can be negotiated

Production Capacity:5 Square Inch/Square Inches per Month

Payment Terms: US $40,000 - 500,000 / Set

Update Time:2011-06-09

Contact Supplier

Product Description

This depositing line is developed for the purpose of high capacity output upto 1200kgs/h of hard candy production

The company has passed the ISO9001:2000 certification and awarded 39 patent rights,

and get CE certification.
This machine we adpot the PLC programed control with Touchscreen,with simply operation ,it can control

the specific weight of the stuff very accurately.

Trait:

Pattern- cell and Servo design allows higher depositor running speed, easy maintenance and cleaning;

Continuous process for minimal product wastage;

Accurate auto-control of deposited volume of the product in PLC;

Easy for the changover of the product dimension and weight;

Full PLC control with LED touch screen for easy operating;

The production capacity from 150 kgs/h to 1200kgs/h;

The whole plant is made of hygienic Stainless Steel(SUS304)

Optional (mass) flowing controlled by Frequency inverters ;

In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;

Dosing pumps for the automatic injection of colors, flavors and acids;

One set of extra chocolate paste injection system for making chocolate-central candies;

Use AUTOMATIC STEAM CONTROL SYSTEM instead of manual steam valve which controls a stable steam supply to the microfilm cooker and can guarantee the cooking temperature keep a less than ±1°C.

“two/three-color stripe depositing”, “two /three–color double layers depositing”, “central filling”, “clear” hard candies and etc. can be made.Moulds can be made according to the candies samples provided by the cu

Technical specifications:

Model		GD150	GD300	GD450	GD600/1200 ( mono-color )
Production capacity		150kgs/h	300kgs/h	450kgs/h	600/1200kgs/h
weight of each candy		Max.6g	Max.6g	Max.6g	Max.6g
Rated depositing times		60n/min	60n/min	60n/min	60n/min
Steam	consumption	250kgs/h	300kgs/h	400kgs/h	450kgs/h
Steam	pressure	0.2~0.6mpa	0.2~0.6mpa	0.2~0.6mpa	0.2~0.6mpa
Compressed air	consumption	0.2m3/min	0.25m3/min	0.3m3/min	0.35m3/min
Compressed air	pressure	0.4~0.6mpa	0.4~0.6mpa	0.4~0.6mpa	0.4~0.6mpa
Conditions	temperature	20~25°C	20~25°C	20~25°C	20~25°C
Conditions	humidity	55%	55%	55%	55%
Total electric power		18kw/380V	24kw/380V	34kw/380V	38/48kw/380V
Length of plant		9.5m	11m	12m	15m

hard candy processing line

Our head company with the manufacturing experience of more than 30 years.

Covering seven hectare, capital of 2.5 billion RMB. We have five mechanical subsidiary factories,

three food experimental factories and one import & export company-Shanghai Yuhan International Trade Co.,Ltd. It is a nation-renowned specialized food machinery factory with considerable scale and strength .

hard candy processing line

Product Type: Candy	Type: Hard Candy	Taste: Sweet
Color: Brown, Clear, Gold, Green, Orange, Pink,...	Shape: Ball	Place of Origin: Shanghai China (Mainland)
material: stainless steel	automatic: full automatie
