lollipop making machine
1.small quantity shrink wrapping industries.
2.pack different sizes,it's simple to adjust.
BTM-400 High quality custom-made lollipop making machine
Uses for lollipop making machine:
This machine is widely used for outside shrink packing by film, such as foodstuff, beverage, pharmacy, video disc, hardware, cosmetics, book, toy and electronic products etc; especially suitable to put and use it in a small room where space is limited such as supermarket, monopolization shop, office and some experimental room etc;
Performance Characteristics for lollipop making machine:
1. Integrated sealing and shrinking in one step.
2. Transparent hood makes the sealing and shrinking visible.
3. Adopts glass fiber cutler's isolator and nickel alloy Cutter in order to result in perfect sealing line, to avoid the film sticking the cutter.
4. It furnished special roller with pin to make small holes on the film.
5.Slidable film holder, can hold various specifications of shrink film and easy to adjust.
6. Might not make over hot around environment after long time operation.
7.Low power consumption, only 2.5kw per hour.
8 .Adopts PPS thermostable cutter clip to bear heavy intension after long time operation
9. The heighth of the package supporting mesh inside the chamber can be adjusted for different sizes of products.
10.BTM-400A equipped stainless steel conveying mesh with the height adjustable transporting the products out after the sealing and shrinking automatically, double increase the packing capacity.
Main Technical Parameters:
Model | BTM-400 |
Max Packing Size | (L+H)≤450mm (W+H)≤330mm (H)≤150mm |
Max Sealing Size | (L)500×(W)400mm |
Packing Speed | 500~800 packs/hour |
Electric Supply & Power | 220V 50Hz 4kw |
Weight | 140kg |
Overall Dimensions | 1380*690×*1065mm |
1. workshop for lollipop making machine
2. showing room for lollipop making machine
3. The exhibition figure for lollipop making machine
4. visit figure for lollipop making machine
5. certificate for lollipop making machine
Type: |
Wrapping Machine
|
Condition: |
New
|
Application: |
Food,Beverage,Commodity,Medical,Chemical,Machinery & Hardware
|
Packaging Type: |
Cartons,Film
|
Packaging Material: |
Plastic,POF film
|
Automatic Grade: |
Semi-Automatic
|
Driven Type: |
Electric
|
Voltage: |
220v
|
Power: |
4kw
|
Place of Origin: |
China (Mainland)
|
Brand Name: |
QCPACK
|
Model Number: |
BTM-400
|
Dimension(L*W*H): |
1380*690*1065mm
|
Weight: |
140KG
|
Certification: |
CE
|
After-sales Service Provided: |
No overseas service provided
|
Name: |
lollipop making machine
|
Other name: |
custom-made lollipop making machine
|
time relay: |
HHD
|
Auxiliary relay: |
OMRON
|
Conveyor motor: |
VTV
|
sealing knife: |
nickel chrome made
|
heating pipe: |
Stainless steel
|
Electrical magnet: |
Landa
|
Hot wind motor: |
NGF
|
Breaker: |
CHNT
|
