chocolate bar wrapping machine
1.carbon steel frame;
2.adjustable speed;
3.Constant temperature.
high speed chocolate bar wrapping machine with MOELLER Emergency stop
1.Machine photos 1:
chocolate bar wrapping machine
2.Machine Photos 2:
chocolate bar wrapping machine
3.Uses :
Suitable for large quantity shrink wrapping industries such as software, foodstuff, cosmetics, printing, pharmacy, flooring, ceramics, beverge and beer etc.
chocolate bar wrapping machine
4.Samples:
chocolate bar wrapping machine
5.Performance Characteristics :
1.The machine adopts imported touching screen,on which all settings and operation can be done. Meanwhile,various product data can be stored in advance,and operator only to select parameters from the computer while usage.
2.According to different collocations for the machine and different products, the max packing speed is up to 80pcs/min.
3.Constant temperature heat sealing and cutting system is suitable for PE. POF etc, industrial standard shrink films, the seal is firm and nice, especially applicable for POF film, adjust the conveyor with the head wheel for packing products of different size. The reliability is higher and easier to operate it .
4.The front feed in systems speed is adjustable, combines a worktable at the end of the tunnel, makes whole machine highly automatic, it runs automatically without an operator comes true.
5.BM-500L Hi-speed hot air circulating shrink tunnel adopts Roller type conveyor, the rollers are covered by silicone gel pipe, they roll automatically, also the conveyor can use Teflon mesh belt or S.S. mesh belt instead of rollers. When shrink PE film, need not the rollers roll, easy to convert it by the handle at the end of the tunnel.
6.The temperature inside the tunnel is even, suitable for shrink PE.PVC.POF films.
7.The inner container forms hot air circulation inside tunnel,the volume of hot air can be controlled by the air doors according to the packing requirements for different products.
chocolate bar wrapping machine
6.Spare parts1:
chocolate bar wrapping machine
7.Spare parts 2:
chocolate bar wrapping machine
8.Main Technical Parameters:
| Model | BTH-450 | BM-500L |
| Max Packing Size | L (W+H) ≤ 400mm (H) ≤ 130mm | (L)1500×(W)450×(H)250mm |
| Max sealing Size | (W+H)≤450mm | (L)1500×(W)500×(H)300mm |
| Packing Speed | 30~80 packs/min | 30~80 packs/min |
| Electric Supply & Power | 380V/50Hz 3kw | 380V/50Hz 16kw |
| Max Current | 10A | 32A |
| Air Pressure | 5.5kg/cm3 | / |
| Weight | 800kg | 650kg |
| Overall Dimensions | (L)2050×(W)1500×(H)1300mm | (L)1800×(W)1100×(H)1300mm |
chocolate bar wrapping machine
9.Spare parts 3:
co chocolate bar wrapping machine
10.Component List:
| No. |
Item |
Brand |
Qty |
| 1 |
Cutting knife servo motor |
PANASONIC (Japan) |
1 |
| 2 |
product feeding motor |
TPG ( Japan ) |
1 |
| 3 |
discharged motor |
TPG ( Japan ) |
1 |
| 4 |
film unwind motor |
TPG ( Japan ) |
1 |
| 5 |
waste film recycling motor |
TPG ( Japan ) |
1 |
| 6 |
PLC |
OMRON (Japan) |
1 |
| 7 |
Touch screen |
MCGS |
1 |
| 8 |
servo motor driver |
PANASONIC (Japan) |
1 |
| 9 |
product feeding inverter |
OMRON (Japan) |
1 |
| 10 |
discharged inverter |
OMRON (Japan) |
1 |
| 11 |
Film unwind inverter |
OMRON (Japan) |
1 |
| 12 |
waste film recycling inverter |
OMRON (Japan) |
1 |
| 13 |
Breaker |
SCHNEIDER ( France ) |
10 |
| 14 |
Temperature controller |
OMRON (Japan) |
2 |
| 15 |
Contactor |
SCHNEIDER ( France ) |
1 |
c chocolate bar wrapping machine
11. Workshop 1:
chocolate bar wrapping machine
12.Workshop 2:
chocolate bar wrapping machine
13.Equipment:
chocolate bar wrapping machine
14.exhibition:
chocolate bar wrapping machine
15.Visit figure:
chocolate bar wrapping machine
16.Certificates:
chocolate bar wrapping machine
17.Shipment Details:
chocolate bar wrapping machine
18.We Promise:
12 Months guarantee,during this period we will offer free replacement after confirming that it is our quality problems.
If you want to know more information about our products welcome to contact us in any time, And welcome to our company!!!
| Type: |
Wrapping Machine
|
Condition: |
New
|
Application: |
Food,Beverage,Commodity,Medical,Chemical,Machinery & Hardware
|
| Packaging Type: |
Cartons
|
Packaging Material: |
Wood
|
Automatic Grade: |
Automatic
|
| Driven Type: |
Electric
|
Voltage: |
380v
|
Power: |
3kw
|
| Place of Origin: |
Shanghai China (Mainland)
|
Brand Name: |
QCPACK
|
Model Number: |
BTH-450+BM-500L
|
| Dimension(L*W*H): |
2050*1500*1300mm+1800*1100*1300mm
|
Weight: |
800kg+650kg
|
Certification: |
CE
|
| After-sales Service Provided: |
Engineers available to service machinery overseas
|
Name: |
chocolate bar wrapping machine
|
Warranty: |
12 months
|
| Cutting knife servo motor: |
PANASONIC
|
product feeding motor: |
TPG
|
PLC: |
OMRON
|
| Touch screen: |
MCGS
|
Temperature controller: |
OMRON
|
Horizontal sensor: |
BANNER
|
| Sealing knife: |
DAIDO
|
Conveyor: |
SIEGLING
|
