High Speed Double Twist Lollipop Automatic Wrapping Machine,China CHLBAO price supplier

High Speed Double Twist Lollipop Automatic Wrapping Machine

FOB Price:Price can be negotiated

Production Capacity:1500 Set/Sets per Year

Payment Terms: US $6,999 - 9,898 / Set

Update Time:2024-07-01

Contact Supplier

Product Description

Servo packing machine
1, Can prevent the empty bag;
2,Can prevent to cut the material functions;
3,Save 10 sets of parameters

High Speed Double Twist lollipop Automatic Wrapping Machine

1 . Scope of application

Suitable to regular products like biscuit, bread, candy, medicine ,daily hotel article, hardware, case ,tray et c .

2. Function Description:

. All the controls are achieved by software, convenient for function adjusting and upgrading.

1.The parts contact with products are made of SUS 304, meeting the food QS and medicine GMP requirements.

2. The operation and maintenance are convenient , intelligent parameter settings.

3. It can store 10 groups of packing parameters thus no need to readjust to reduce material costs.

4. Intelligent control module makes temperature control more stable.

5. Servo motion controllers track synchronously thus it's no need to adjust the Cutter speed.

6. Mature servo control technology, overload protection technology and leakage protection technology protect the machine , extend the service life of machine

7. Suitable for packing various kinds of pipe products.

8. Self diagnosis failure function, clear failure display

3 . Technical Specifications :

Single knife	Bag size: L (50-6000) * W (50-140) * H (3-55) mm
Single knife	43 meters/min
Thickness of film	25-70 um
Width of film	≤320 mm
Dimension of film roll	outer diameter ≤300 mm inner diameter ≤75mm
Power requirement	220V, 50HZ, 3KW
Machine size	L 3900* W 940* H 1500
Machine Weight	600KG
Optional device	printer, gas charging device, feeder, tidier

4 . Origin of each components

Touch screen: Siemens/Germany Switch series: Schneider/French

PLC controller: Siemens/Germany Module: Siemens/Germany

Servo motor: TECO/Taiwan Inverter: Schneider/French

Relay: Omron/Japan Date printer: Di ngsheng /Shangha i

Photo-sensor: SICK/Germany

5. EACH CLIENT CAN ENJOY THE FOLLOWING SERVICES

1) Free consultation service before, during, and after sales;

2) Free project planning and design services;

3) Free debugging of equipment until everything is functional;

4) Free management of equipments' long distance shipping;

5) Free training of equipment maintenance and operating personally;

6) Free new production techniques and formulas;

7) Provide 1 year complete warrantee and lifetime maintenance service.

Customer service :

The company will work with all areas of business partners to provide automated data collection program planning users,

design, configuration, installation, implementation and upgrades.The company will ensure the successful implementation

of packaging machinery products provide comprehensive and specialized services.

Technical Support:

Service Department will be responsible for the user's service and maintenance support.Through the improvement and advanced techniques,

such as technical maintenance, user support centers, systematically ensure the timeliness of service, continuity and professionalism, and provide

quality packaging machinery.

6 . Spare part with machine:

Heater bar : 2pcs Hex driver : 1set

Solid-state relay : 1 pcs Adjustable wrench : 1pcs

Cutter : 2pcs Screwdriver : 2 pcs

simple photos about us

7. Certification :

our honor

Packing detail:film + wooden case

Type:	Wrapping Machine	Condition:	New	Application:	Food,Medical,Chemical,Machinery & Hardware
Packaging Type:	Bags,Film,Foil	Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	220V,380V	Power:	3KW
Place of Origin:	Guangdong China (Mainland)	Brand Name:	CHLBAO	Model Number:	CB-300S
Dimension(LWH):	L 3900* W 940* H 1500mm	Weight:	600KG	Certification:	CE SGS BV
After-sales Service Provided:	Engineers available to service machinery overseas	Screen:	touch screen Automatic Wrapping Machine	temperature control:	intelligent Automatic Wrapping Machine
used range:	Automatic Wrapping Machine Machine for food
