Horizontal flow packaging machine for chocolate bars, candies (DCTWB-400B),China Chuansong price supplier

Horizontal flow packaging machine for chocolate bars, candies (DCTWB-400B)

FOB Price:Price can be negotiated

Production Capacity:40 Set/Sets per Month enlarging capaci

Payment Terms: US $7,000 - 8,000 / Set

Update Time:2014-09-28

Contact Supplier

Product Description

chocolate bar packing machine, hot sale
1: Self failure diagnosis,clear failure display
2: PLC Control, good quality, economic

DCTWB-400D

Horizontal flow packaging machinery for chocolate bar, candies, Pies

1:Self failure diagnosis,clear failure display
2:PLC Control, packing for cakes

Specifications

Type	DCTWB-400B
Film width	Max.400mm
Bag length	180-400mm
Bag width	50-185mm
Product height	Max.60mm
Film roll diameter	Max.320mm
Packaging rate	30-180bags/min
Power	220V 50/60Hz 2.6KW
Machine size	(L)4020(W)800(H)1450mm
Machine weight	900kg
remarks	Option air filling device

Feactures

1. Dual frequency conversion control, bag length can be set and cut in one step, saving time and film.

2. Interface feactures easy and quick setting and operation.

3. Self failure diagnosis, clear failure display.

4. High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.

5. Temperature independent PID control, more suitable for packaging different materials.

6. Positioned stop function, without sticking knife or wasting film.

7. Simple driving system, realible working, convenient maintenance.

8. All controls realized through software, easy for function adjusting and technical upgrade.

Applications:
Packaging various kinds of reqular objects like biscuits, pies, chocolates, candies, bread, cookies, muffins, desserts, instant noodles, moon-cakes, cakes, Rice cakse, drugs, daily appliances, industrial parts, paper boxes, plates, soap, hotle disposable appliances etc.

Packing samples:

After-sale service:

1. One year quality guarantee, operating manual, tools and spare parts will be shipped with machine together.

2. Supply spare parts at low cost for life span.

3. Online technic service and offer solution within 24 hours in case of problem arise.

4. Staff training when you come to our factory.

Remark:

1. Machine Package: plastic film + wooden case.
2. Payment terms: 30% deposit should to be paid when order, 70% balance will be paid before delivery the goods to Chinese port.
3. Lead time: 20-35 days after receipt of desopit .
4. Stochastic bag forming 1 pcs.
5. Price availability: within 2 months.
6. Warranty: one year (Attention: Machine's warranty range don't include quick-wear parts; for other parts, providing new free parts for clients in a warranty period).
7. Tenure of use: over 10 years.

Type:	Wrapping Machine,Packing Machine, Wrapping Machine	Condition:	New	Application:	Food,Beverage,Commodity,Medical,Chemical,Machinery & Hardware,Apparel,Textiles
Packaging Type:	Stand-up Pouch,Bags,Film,Pouch,Case,Plastic bag	Packaging Material:	Plastic	Automatic Grade:	Semi-Automatic
Driven Type:	Electric	Voltage:	220V	Power:	2.6 KW
Place of Origin:	Guangdong China (Mainland)	Brand Name:	Chuansong	Model Number:	DCTWB-400B
Dimension(LWH):	(L)4020(W)800(H)1450mm	Weight:	900kg	Certification:	CE, SGS
After-sales Service Provided:	Engineers available to service machinery overseas	Machine material:	Carbon steel/stainles steel	All parts contacted with product:	Stainless steel
Shape of sealed bag:	Back bag	Optional parts:	Code printer/Gusseting device	Brand:	chuansong
Packing:	plastic roll film	PLC:	panasonic	interface:	keypad screen
packing speed:	30-180bags/min
