Imported Polypropylene(PP) membrane water /colation /coconut water filtration/ treatment/ filtering ,China TS Filter price supplier

Imported Polypropylene(PP) membrane water /colation /coconut water filtration/ treatment/ filtering

FOB Price:Price can be negotiated

Production Capacity:500000 Piece/Pieces per Month

Payment Terms: US $1 - 10 / Piece

Update Time:2014-09-16

Contact Supplier

Product Description

1.Filter with imported PP membrane
2.superior dirt-holding capacity
3.long service life and high flow rates
4.economical

Imported PP Filter Cartridge for air filter and liquid filter

Absolute rating

Imported polypropylene membrane which can provide absolute rating filtration.

C omplete Polypropylene structure

Made of 100% high quality polypropylene material

Wide chemical compatiblity of the Filter Cartridge

Can be used in the solvent which PH value is from 1 to 13

No media migration into the process fluid

All the material have passed the migration test according to FDA and 2002/72/EC

Effective Filtration Area of each filter cartridg e :0.65M2 per 10"

Filter Cartridge Structure Materials

Filter Media	Polypropylene membrane
Support Layers	Polypropylene
Inner core	Polypropylene
Outer Support	Polypropylene cage
Adapter	Polypropylene with encaptulated;SUS304 reinforcing ring

Filter Cartridge Dimensions (Nominal)

Outer Diameter: 69mm (2.75")
Inner Diameter: 33mm (1.30")
Length: 10"-; 254mm
               20"- 508mm
               30"-762 mm
               40"- 1016mm
*(Length is based on DOE Adapter)

Filter Cartridge Purity

Free of surfactants, resins, binders and adhesives.
Standard: Clean and flushed with Pyrogen-free water.
Vacuum packing

Typical Applications

Pharmaceutical; APIs, Biologics;

Fine chemicals;

Fermentation
Food & Beverages, Wine, Beer, Mineral Water;
Semi-Conductor, LCD Display; Discs.

Operation Conditions

Normal Operating Temperature	Up to 55 °C( 131 °F)
Max. Operating Temperature	80 °C( 172 °F)
Max. Differential Pressure:
Normal Flow Direction	4.2 bar (60psi) at 25 °C( 77 °F)
Reverse Flow Direction	2.1 bar (30psi) at 25 °C( 77 °F)
PH Value compatibility	1-13

Material Safety

Meet the current FDA and 2002/72/EC standard.

Typical water flow rate (10”)

Liquid Retention Ratings (um) Test

100% Integrity Test

Certificate

Place of Origin:	Zhejiang China (Mainland)	Brand Name:	TS Filter	Model Number:	IPP filter
Filter Class:	Micron Filtration	filter media:	imported polypropylene	inner core:	PP
filter support layer,cage:	PP	filter diameter:	69mm(out);33mm(inner)	filter length:	10'',20'',30'',40'',5''
micron:	0.5um,1um,2um,5um	filtration area:	0.65m2(10'')	efficiency:	>99.99%
Certificate:	FDA,2002/72/EC

Company Profile

Name: Hangzhou Tianshan Precision Filter Material Co., Ltd.

Main Products: Membrane Filter Cartridges,Pleated PP Membrane Filter Cartridges,Pleated PES Membrane Filter Cartridges,Pleated PTFE Membrane Filter cartridges,Pleated PVDF Membrane Filter cartridges

Business Type: Trading Company

Total Employees: 11 - 50 People

Established Year: 2001

Main Markets: Eastern Europe, South Asia, Southern Europe, Western Europe, Eastern Asia

Address: No. 2630 Nanhuan Road, Binjiang district

Hangzhou Tianshan Precision Filter Material Co., Ltd. is an ISO9001:2000 certified company.

Since 2001, we have focused on manufacturing pleated membrane filter cartridges and filtration equipment. Our sincere service and excellent quality win the trust of customers. Many famous pharmaceutical groups in China choose our products to purify the water, such as:
Lijun Pharmaceutical Co., Ltd. - Listed on Hongkong with over 2,000 employees;
Harbin Pharmaceutical Group - one of the top 500 large scale groups in China.

Our main products:
1. Pleated membrane filter cartridges: PP, PES, PVDF, PTFE, nylon (PN6, PN66), ACF (activated carbon filter), melt blown filter, string wound filter, etc.
2. Antiseptic shelter filter
3. Filtration equipment: made of stainless steel (SS304, SS316)

Applications:
our products can be widely used in many industries including medicine production, food and beverage production, biological engineering, microelectronic industry, fine chemical industry, galvanization, super purification of water, sewage processing, etc.

Quality Assurance:
Complete quality management system;
Workshop organized as per pharmaceutical criterions (GMP);
Materials reach pharmaceutical grade;
Membranes are made by American companies, like MILLIPORE, PALL, etc. (certificates are available);
Integrity testing;
Strictly inspected by advanced instrument before packing.

Welcome to visit us. more
