Lollipop Sticks Extractor Machines|Lollipop Sticks Extracting Machine|Lollipop Sticks Machine

1, LGE-55 Extractor Machines

(Including Vacuum Feeder and Hopper, which has the function of drying)

1)   Model: LGE-55

2) Screw: Special Screw

Diameter:55mm

Aspect ratio : 28:1

Material: 38CrMoAlA

Surface treatment: Nitriding mirror polishing

3) Cylinder (material batterl)

  Material: 38CrMoAlA

  Inner surface tratement: Nitride Grinding

  Heating control area: 6 zones(adopted HUB temperature table of Taiwan)

  Cyclinder cooling zone   3 zones

  Cooling system: Multi-blade cooling fan from Taiwan

  The material of fan shield: SUS304 stainless steel

4) Gear Reducer Box with cooling system( Italy Technology, square hardened high torque reduction gear box)

  The material of the box: 40CrMnMo

The form of the gear: Helical gear

The material of the gear: 20CrMnTi (Hardened, grinding treatment)

The mateirl of Axis: 40Cr

Lubrication system: Pressure lubrication system

5) Control system

  The power: 15kw

  Control method: Variable frequency control

6) Dimension: 2300*1450*1550mm

Weight: 800kg

2, LGE-30 Extractor Machine

1 ) Model: LGE-30

2) Screw: special screw

Diameter: 30mm

Aspect ratio : 25:1

Material:38 CrMoAlA

Surface treatment: Nitriding mirror polishing

3 ) Cyclinder

Material: 38CrMoAlA

Inner Surface Treatment: Nitride Grinding

Heating control area : 3 zones(adopted HUB temperature table of Taiwan)

Cyclinder cooling zone: 2 zones

Cooling System: Multi-blade cooling fan from Taiwan

The material of fan shield: SUS304 stainless steel

4) Gear Reducer Box(Italy Technology, square hardened high torque reduction gear box)

The material of box: 40CrMnMo

The form the gear: Helical gear

The material of gear: 20CrMnTi

The mateirl of Axis: 40Cr

Lubrication system: Pressure lubrication system

5) Control System

Control power: 2.2KW

Control method: Variable frequency control

6) Dimension: 1300*1150*1250mm

Weight: 500kg

The spare parts:

1 ) Control Cabinet

2 ) The whole set of mould:

Sticks with Single notch, diater of 5mm, length of 80mm

Sticks with double nothc, diameter of 3mm, length of 63mm

The normal sticksw with diameter of 4mm and length of 75mm

3 ) Vacuum Cooling Tank with length of 8 meters , made of stainless steel 304

4) one set of adjustable sind shelf

5) one set of Vacuum Pump with power of 1.5kw

6) one set of traction cutting machine( doubel knives)
