cocoa powder making machine
1 Vacuum low-temperature drying
2 automatic and continuous drying
3 CIP cleaning
4 GMP Standards
Cocoa Powder Making Machine
1 Application Scope:
Liquid or paste with fluidity, which can be pumped into our machine, such as:
1), malt extract 2), Cocoa 3), chocolate beverage 4), Plant Extract 5), liquid chemicals 6), Food Additive 7), biological, and so on
2 Working Principle :
VBD can accomplish continuous feeding and discharging of material in vacuum state, turn the traditional static drying to dynamic vacuum drying, reduce traditional drying time from 10-20 hours to 30-60 minutes, reach the goal of adjusting drying temperature according to different materials, and solve the problems difficult for spray dryer, and also solve the problem of denaturalization of material due to the long time drying by traditional oven. VBD can create the drying process which traditional dyers can not fulfill. The color, solubility and the preservation of the active ingredient of the dried product by VBD is unrivaled.
3 Vacuum Low-temperature Continuous Belt Dryer’s drying process:
4 Technical Parameters of dryers for liquid:
5 Advantages:
Short drying time (adjustable between 20-90 minutes)
Minimum loss of aroma
Little loss of product
No Oxidation of product
No Mechanical stress
Solvent recycling possible
Low product temperatures (adjustable between 20°C-150°C)
Less energy consumption
Completely closed system
No pollution of environment
Controllable maillard reaction
Instant properties of the drier products
PLC Automatic control system
CIP Cleaning system
GMP Standards
6 Some of our oversea customers :
Note:
Our Vacuum Belt Dryers are system equipment, including free installation, debugging, operators training. The picture shows the main body of the whole system. Following lists the main composing systems:
1 |
In feed system |
2 |
Main body of the equipment |
3 |
Heating-cooling system |
4 |
Belt convey system |
5 |
Distribution system |
6 |
Guillotine system |
7 |
Discharging system |
8 |
Rectify system |
9 |
CIP Cleaning system |
10 |
Vacuum system |
11 |
Pneumatic control system |
12 |
PLC Automatic System |
For key technology, Minjie people keep developing to catch up with world advanced level.
For key parts, Minjie dryers only use products from first class supplier around the world.
Place of Origin: |
Shanghai China (Mainland)
|
Brand Name: |
Minjie
|
Model Number: |
MJY4-2 to MJY20-10(by customers needs to choose)
|
Type: |
drying equipment
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Material: |
304stainless steel
|
Color: |
stainless steel color
|
Heating source: |
electricity, steam, hot oil or hot water
|
Drying Temperature: |
adjustable between 20℃-150℃
|
category: |
cocoa powder making machine
|
Drying material state: |
liquid or paste
|
Voltage: |
10-80kw
|
Operation: |
automatic
|
Automatic control way: |
PLC
|
Cleaning: |
CIP
|
