This Equipment standard inlet steam proportion valve, high precision temperature of Sterilization.
Introduction of milk processing machine
This milk processing machine is widely used for determining and updating of the original recipe about raw materials of Milk, juice, tea drinks, milk drinks, ketchup, condiments, beer, butter, ice cream, egg products, powder and other products, screening product taste, color evaluation, Stabilizer / Emulsifier applications, new R & D and small batch production using.
This milk processing machine is ideal for handling capacity from 300 to 1500 kg production fluid materials used for sterilization. This milk processing machine integrates heat pasteurization, sterilization, cooling, hot filling into one. Automatic control, touch screen dynamic display system. This milk processing machine is the ideal equipment for small school and community pasteurized milk enterprises.
This milk processing machine standard inlet steam proportion valve, high precision temperature of sterilization, this is very suitable for high quality requirements of the disinfection product and peri-urban large-scale food production enterprises.
Features of milk processing machine
This milk processing machine includes three parts: regeneration, heating and cooling , the sheet and tubing type of sterilization can be combined in various forms, And with two separate heating and cooling section to line homogenizer. Product temperature can reach 142 °C. All parts in contact with the product of this milk processing machine are made of 316 stainless steel, Plate gaskets and seals made of food-grade Viton, product pipelines connecting with DIN sanitary fittings. In the display output, the production casing type milk processing machine configuration touch screen, PLC program control, it’s can be dynamically reflect of the product temperature, flow and other parameters, the gauge and digital sensor can be selected according to user requirements, Therefore, the milk processing machine is able to adapt to a variety of materials for industrial production.
Parameters of milk processing machine
1. Occupies only 5 to 6 m2
2. Minimum feeding amount 50L
3. Material flow: 300-1500L / H (depending on model)
4. Highest degree of sterilization temperature :130-142
5. Temperature control ± 1 °C
6. Sterilization time: customers make their own determination
7. Maximum particle material: 8mm
8. Heating device: external steam
9. Sterilization methods: sterilization casing
10. Equipment cleaning: standard power pump
11. Materials temporary storage tank: 30 ~ 50 liters (depending on model)
12. Equipment Material: high quality SUS304
Pictures of milk processing machine
Milk processing machine
Final products of milk processing machine
Thank you for your interest about our milk processing machine
Place of Origin: |
Shanghai China (Mainland)
|
Brand Name: |
BETTER
|
Model Number: |
HTS
|
Type: |
Tubular UHT Machine
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Temperature control: |
± 1 ℃
|
Sterilization time: |
customers make their own determination
|
Maximum particle material: |
8mm
|
Heating device: |
external steam
|
Sterilization methods: |
sterilization casing
|
Equipment cleaning: |
standard power pump
|
Materials temporary storage tank: |
30 ~ 50 liters (depending on model)
|
Equipment Material: |
High quality SUS304
|
