oil Filling Machine
Fast delivery
Hot sale
Good quality
Specifications
oil production machines
1.The speed of filling is fast
2.The liquid amount is controlled accurately
3.No oil waste or leak out
Oil production line
This machine is a linear type filling machine. It adopts electromechanical integration control system. It is mainly used to filling a variety of viscous, non-viscous, corrosive and non-corrosive liquids. It is suitable for small quantitative packages of vegetable oil, lubricants, chemical liquids, and so on.
Characters:
1. It is equipped with original German Siemens PLC as control system, which can ensure the machine has good stability.
2. Motors and pneumatic controlling elements are all imported brands, such as AIRTAC, Siemens, etc.
3. Photoelectric detection system is from German products with high sensitivity.
4. The advanced anti-leakage device ensures no oil leakage occurs in filling process, so it is economical and save oil source, and keep filling area and conveyor clean.
5. Delivery is stepping, primary delivery adopts variable frequency control which has higher efficiency. The following process (stamping, ink-jet printing, light-check and case-sealing, etc) adopts special double dislocation connection, which makes sure the whole production line more accurate and smooth.
6. High and low double speed filling avoids overflow and increase the production efficiency.
7. The control system has intelligent protection function. When there is any problem, bell alarms and machine stops work. The problem is shown on PLC screen.
8. Filling volume is adjustable. When changing for another filling volume, only need write the pointed filling volumes into PLC control, so the change is easy and simple.
Technical parameters:
| Item |
8 heads automatic edible oil filling machine |
| Number of filling head |
2,4,6,8,12 etc for choose |
| Filling volume |
500-2500ml(it can be change for your demand) |
| Filling form |
Piston-type filling |
| Theoretical filling speed |
10-50 bottles/min |
| Filling precision |
1% |
| Conveying speed |
5-15m/min |
| Conveyor belt |
3M POM chain type |
| Width of convey belt |
82mm |
| Conveyor belt ’ s distance from the ground |
750mm ± 20mm |
| Total power |
220V,50Hz,2.2KW,AC SINGLE-PHASE |
| Procedure control |
PLC and touch screen control |
| Air supply |
0.5-0.8Mpa |
| Size of the machine |
Customized |
| Weight of the machine |
About 400KG |
Product show:
After sales service
1.one year warranty for the whole system
2.free equipment installation and debugging
3.we can provide internship service and help you train the operator and mechanic
4.we can help you to design the product line,workshop and provide turn-key project.
5.24 hours technical support by email
If you need , Please contact us as soon as possible !!! We will offer you more infomation about our factory and production ~~
| Type: |
Filling Machine
|
Condition: |
New
|
Application: |
Food,Beverage,Commodity,Medical,Chemical,Machinery & Hardware,Apparel,Textiles
|
| Packaging Type: |
Cartons,Cans,Bottles,Barrel,Stand-up Pouch,Bags,Pouch,Capsule,Case
|
Packaging Material: |
Plastic,Paper,Metal,Glass,Wood
|
Automatic Grade: |
Automatic
|
| Driven Type: |
Electric
|
Voltage: |
110V 220V 380V
|
Power: |
9.78KW
|
| Place of Origin: |
Jiangsu China (Mainland)
|
Brand Name: |
KEYUAN Filling Machine
|
Weight: |
3000
|
| Certification: |
CE ISO
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Model: |
Filling Machine
|
| Guarantee: |
1 Year
|
Feature: |
Fruit juice/pure water/soy and so on
|
