Pistachio Nuts packing machine &auto weighing and packing machine for pistachio nuts
I. Application
Suitable for rice ,food,fried food,shrimp strip,sea shell,seeds.seed,soybean,peanut etc.
pistachio nuts packing machine &auto weighing and packing machine for pistachio nuts
II. Features
1. imported PLC and color touch screen , interface operatin , easy opration,intuitionstic and efficient.
2 .separate pneumatic control and power control , low noise ,stable operation .
3.Vacuum film feeding device and two synchronous belt device with servo motor control system , less film pulling resistance , high orientation precision,bag desigh can be kept well .And belt are more duable .
4.External film feeding machanism .Film setting is easier and faster .
5.close down type mechanism , defending dust into inside of machine .
6.works with metering device , it can complete the whole procedure of metering ,filling ,bag forming , Date printing ,exhausting ,counting automatically.
pistachio nuts packing machine &auto weighing and packing machine for pistachio nuts
III.Specification
| type | ALD-520 |
| Film width | 120-380mm |
| Air consumption | 0.65Mpa,4m³/min.6kg/cm³ |
| Bag length | 80-350mm |
| Bag width | 100-250mm |
| Maximum external diameter of coiled meterial | Max.360mm |
| Packing speed | 5-70 bags/min |
| Packing thickness | 0.04-0.08mm |
| Power supply specification | 220V.50/60Hz.3kw |
| Dimension | 1430*1200*1700(L.W.H)mm |
| Total weight of machine | 650kg |
FOSHAN AOLIDE Packing Machinery Co.,Ltd is a professional packaging machine manufacturer with 11 years' experience in China. We offer all kinds of pillow packing machine and vertical packing machine , for food packing , hardware packing , powder packing , etc.
