PLC control lollipop making machine

FOB Price:Price can be negotiated

Production Capacity:10 Set/Sets per Month

Update Time:2014-09-25

Contact Supplier

Product Description

advanced equipment to produce lollipop
controlled by a PLC
vacuum cooking

Automatic Lollipop Depositing Line(with stick automatic insert system)

The QHB series lollipop depositing line is an advanced equipment to produce lollipop.

The operation is controlled by a PLC/program for the vacuum cooking, feeding, and depositing.

It can be in-line injection, dosing and pre-mixing for the proportional addition of liquid colors, flavors, and acids.

The line is composed of cookers, storage tank, micro-film cooker, depositing, moulds and industrial cooling tunnel.

It can produce two color striped, two color layers, one color and central-filled lollipop.The line is a full-automatic plant equipped with an automatic stick insertion system.
Moreover, just change the moulds ,tt is available to produce both hard candy and lollipop on the same depositing line.

Attn: Annie Tsui

E-mail: sales11 @ jouyu.com

T: 86 21 3202 0358 * 815

F: 86 21 3202 0328

Parameter:

MODEL	QH150	QH300	QH450	QH600
Capacity(kg/hr)	150	300	450	600
Max candy weight	26g	26g	26g	26g
Lollipop Diameter	Flat:18-28mm Ball:Max 25mm
Depositing speed	55-65n/min	55-65n/min	55-65n/min	55-65n/min
Stick Specification	60-100mm	60-100mm	60-100mm	60-100mm
Compressed air requirement	0.2m³/min, 0.4-0.6Mpa	0.2m³/min, 0.4-0.6Mpa	0.2m³/min, 0.4-0.6Mpa	0.2m³/min ,0.4-0.6Mpa
Working condition	Temp:20-25°C Humidity:55%	Temp:20-25°C Humidity:55%	Temp:20-25°C Humidity:55%	Temp:20-25°C Humidity:55%
Total Power	18kw/380V	27kw/380V	34kw/380V	38kw/380V
Total Length	17m	19m	19m	22m
Total Weight	3500kg	4000kg	4500kg	5000kg

Condition:	New	Place of Origin:	China (Mainland)	Brand Name:	JY
Model Number:	QH	Application:	Candy	Voltage:	380V
Power(W):	18-38kw	Weight:	3500-5000kw	Warranty:	half a year
After-sales Service Provided:	Engineers available to service machinery overseas
