Marshmallow machine
1.Produce various cotton Candy
2.Temperature Control Function
3.Save Energy Design
Professional automatic commercial industrial stainless steel marshmallow machine
Introduction
The Cotton Candy Production Line is based on the latest technology , is a complete plant for continuously producing various kinds of cotton candies (marshmallow) which comes in a variety of colors and shapes.
1) In the premixer, all the ingredients to be dissolved and cooked. (An automatic one can be used for auto weighing and mixing).
2) Then the basic slurry is continuously pumped to a cooker till the final moisture level is reached.
3) After cooking, the slurry will be cooled and mixed with a separate whipping agent solution.
4) Then the cooled “marshmallow base” is passed through the continuous aerator.
5) The product then be divided and injection with different colors and flavors.
6) The multi-color product is extruded ,and transported on a cooling conveyor for cooling down;
7) The conditioned marshmallows are dusted top and bottom with starch, or a mixture of both starch and icing sugar in a separate dust cabin; the product is cut to the required length here.
8) The dust cabin is kept under a strict control to prevent the “dust” spreading throughout the plant. The excess starch/sugar is removed.
9) The final is transferred to a packaging machine .
Related equipments
Technical Parameters
Model |
HA-DRCC 1 50 0 |
Production capacity |
300 kg/h |
Making size of the product |
20~50 mm |
Steam consumption Steam pressure |
250 kg/h 0.2~0.6 M p a |
Electric power needed |
20Kw /380V |
Compressed air consumption Compressed air pressure |
1.5m 3 /min 0.6-0.8M p a |
Conditions needed for the cooling system: 1. Room temperature /degree 2. Humidity (%) |
20~25 45~55 |
Gross weight |
4000Kg |
L ength |
2 0 m |
Samples of Finished Products
Services
We offer the cotton candy production line, and also offer the jam filled cotton candy production line, and other candy production line, like: lollipop, soft candy, hard candy. If you have interest, please contact me freely
Condition: |
New
|
Place of Origin: |
Henan China (Mainland)
|
Brand Name: |
HA
|
Model Number: |
HA-DRCC1500
|
Application: |
Candy
|
Voltage: |
380V
|
Power(W): |
20Kw
|
Weight: |
4000Kg
|
Dimension(L*W*H): |
20000*1500*2600mm
|
Warranty: |
I Year
|
Brand: |
HA
|
Name: |
cotton candy machine
|
Usage: |
various cotton candy
|
Electric power needed: |
20Kw/380V
|
Model: |
4000Kg
|
Length: |
20 m
|
Production capacity: |
300 kg/h
|
Material: |
stainless steel
|
Control: |
automatic
|
Type: |
complete extruded
|
