Red wine pouch with spout filling capping packing machine

FOB Price:Price can be negotiated

Production Capacity:30 Set/Sets per Month

Payment Terms: US $6,500 - 7,000 / Set

Update Time:2014-09-19

Contact Supplier

Product Description

1:PLC human Chinese and English control
2: Automatic filling sealing packing Machine
3:patent machine in the world

Hongfa Packaging Technology institution

ADD:Zhifangtou Industry Park Cangzhou city, Hebei province, China.

We are a provincial technological manufacturer specialized in packaging technology and food machinery research, This factory produce aseptic packaging machine, ice pop maker, multi-purpose filling, sealing capping machine, high speed shear emulsifying machine, aseptic brick machine, liquid filling machine, Juice filling and capping , special bag filling capping machine, etc. and also can provide customized products according to different requirements.

Some of types of machine we are producing as follows:

1. stand up with cap or doypack pouch/bag/ schet filling sealing capping machine

2.Main specifications

Model	HF-ZLD-D
Production Capacity	500-1000bags/hour
Capacity	100-350ml
Power	1kw
Machine weight	About 180kg
Size	110013001220mm
Power	220V.50Hz
Max pumping speed	0.35m3/min
Material	Stainless steel
Package	Wooden carton or plywood case

3.Function and characteristics

♥ HFZLD-D doypack Filling Machine is Easy to operate, adopt advanced PLC from Germany Siemens, mate with touch screen and electric control system, the man-machine

interface is friendly.

♥ Horizontal conveyer style to giving bag: It can put on more bags on the bag storage,

save your time.

♥ Fully automatic spout pouch supply, liquid filling, cap supply, cap arrange and capping.

Automatic quantitive filling and control liquid level.

♥ The capping device can be adjusted, so it is easy to make the cap loose or tight, ensure the cap make tight.

♥ Safety device: Machine has emergency stop device, protect from abnormal situations.

♥ The whole machine adopts stainless steel material and international brand parts according to the food hygienic requirements, guarantee hygiene and security of the food.

pouch(stand up bag) filling and

capping machine
HF-ZLD-C

Technical parameters:

Efficiency:2500-3000bags/hour

Weight:1T

Power:380V 50HZ

Power:4.5kw

Packing capacity rage:100-500ml

pouch(stand up pouch ) filling and

capping machine
HF-ZLD-B

Technical parameters:

Efficiency:2500-3000bags/hour

Weight:1T

Power:380V 50HZ

Power:4.5kw

Packing capacity rage:100-500ml

pouch(stand up pouch ) filling and

capping machine
HF-ZLD- A

Technical parameters:

Efficiency:2500-3000bags/hour

With full enclosed clean area working.

Weight:1T

Power:380V 50HZ

Power:4.5kw

Packing capacity rage:100-500ml

STAND UP POUCH WITH SPOUT

MOUTH TO MOUTH ICE CREAM/ICE POPSICLE FILLING MACHINE

Type:	Filling Machine,full automatic	Condition:	New	Application:	Food,Beverage,Commodity,Medical,Chemical
Packaging Type:	Cartons,Cans,Bottles,Barrel,Stand-up Pouch,Bags,Pouch,Capsule,Case	Packaging Material:	Plastic	Automatic Grade:	Automatic
Driven Type:	Electric	Voltage:	220V	Power:	1kw
Place of Origin:	Hebei China (Mainland)	Brand Name:	xinhongfa	Model Number:	HF-ZLD-D
Dimension(LWH):	1300x1100x1220mm	Weight:	180KG	Certification:	CE
After-sales Service Provided:	Engineers available to service machinery overseas	model:	full stainess steel
