ZGX-4 Stand up pouch packing machine / Stand-up Pouch filling & capping machine (Packaging machinery, Packaging machine)
Applicable Products:
J elly, Jelly drinks ,Pudding, Yogurt, Ointment and soybean milk , Milk tea, honey
Outstanding Features and Construction: .
l Two-step piston filling device permits adjustment of filling quantity.
l Stop working without pouch to protect the machine safely.
l The machine has the advanced programming-controller from Japan and Frequency conversion system.
l All parts which are directly contact with food are made of stainless steel. So it conforms to the requirements of Food Grade and looks bright and orderliness.
Note : we can add or delete some devices according to your requirements!
Technical Specification
Model |
ZGX-4 |
Packaging Speed: |
4,000 --5,000 pcs / hour |
Filling Volume: |
50-300 ml |
Power: |
3-phase 4-line socket(380V50HZ) |
Electric Machinery Power: |
1.5kw |
Heat Up Power: |
1.6kw |
Air Pressure: |
0.7Mpa |
Max.Air Consumption: |
0.8m 3 /min |
Timing Mode |
Stepless speed regulating |
Machine Dimension(L*W*H) |
4,000*2,200*1,900mm |
Package Dimension(L*W*H) |
4,150*2,350*2,050mm |
G.W. |
2700kg |
N.W. |
2500kg |
Note: All specifications, design and characteristics shown in the catalogue are subject to change without prior notice. |
Founded in 1998, XinChuang Packing & Food Machinery Company is a company that integrates research and development, manufacture, sales and consultation. Our products are exported to the USA, Japan, Australia, Indonesia, India, Malaysia, New Zealand, France, Russia, Kazakhstan, Vietnam and some African countries. Moreover, we have won local and national recognition for our high quality products and excellent services.
