horizontal packing machine
1.easy operation
2. PLC system
3.high quality
4.CE approved
TCZB-320B Automatic horizontal flow packing machine price for chocolate bar
Horizontal packing machine specifications
Type |
TC -250 |
TC -320 |
TC -350 |
TC-400 | TC-450 | TC-600 |
Film width |
250mm | 320mm | 350mm | 400mm | 450mm | 600mm |
Bag length | 40-280mm |
65-300mm | 65-330mm | 180-400MM |
130-450MM | 130-450MM |
Bag width | 30-110mm | 50-160MM | 50-160mm | 50-190mm | 60-210mm | 50-280mm |
products High | Max.55mm | Max.60mm | max.70mm | max.80mm | max 90mm | max95mm |
Packing speed | 40-230bag/mins | 40-230bag/min | 40-230bag/min | 30-180bag/min | 30-180bag/min | 30-150bag/min |
Power | 220V 50/60HZ 2.4KW | 220V 50/60HZ 2.6KW | 220V 50/60HZ 2.6KW | 220v 50/60hz 2.6KW | 220v 50/60hz 2.6KW | 220v 50/60hz 2.6w |
Machine size | 3770x670x1450 | 3770x720x1450 | 4020x745x1450 | 4020x77x1450 | 4020x820x1450 | 4020x1000x1450 |
Machine Weight | 800kg | 900kg | 900kg | 900kg | 900kg | 900kg |
Horizontal packing machine a pplications
Food:mood cake, bread , biscuit ,cakes, of objects with regular
Others: tape, card, packets , plasitc cup , disposable shoes etc regular objects
Horizontal packing machine d escriptions
1. Dual frequency conversion control, bag length can be set and cut on one step, saving time and film.
2. Interface features easy and quick setting and operation.
3. Self failure diagnosis, clear failure display.
4. High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
5. Temperature independent PID control, more suitable for packing different materials.
6. Positioned stop function, without sticking knife or wasting film.
7. Simple driving system, reliable working, convenient maintenance.
8. All control is realized through software, easy for function adjusting and technical upgrade.
Shipping:
Upon receipt of payment , delivery date will be in 3-15days,
By Air, by Sea or by Express (DHL etc)
Shipment cost will depend on the destination, shipment way,size and the weight of the goods
Our Certification
1)Why should you choose Taichuan Packaing machine ?
Taichuan is specializing in packing machine for 10 years,with good quality and competitive price.
2)Can you provide after-sale service?
Of course,we have engineers available to service machinery overseas .
3)Can I visit your factory and send workers for learning ?
Yes,we will provide you about the skill of packing machine
4)What is Our Advantages?
1. Rapid response on any inquiry.
2. Competitive price.
3. Professional inspection department to guarantee quality.
5)How to Contact Us?
Send your Inquiry Details in the Below, Click " Send " Now!
Optional accessories:
1:Date Coder 2:Touchable Screen 3:Automatic Punching Device
4:Alternative sealing patterns and notch 5:Auto labeling device 6:Deoxidizer chute device
7:Gas flushing device 8:Alcohol spraying device 9:Auto feeder
Payment:
1:T/T and Western Union are accepted
2:30% deposit before production and 70% balance before shipment
3:All banking charges outside China are on buyers
Type: |
Packaging Machine"> Multi-Function Packaging Machine
|
Condition: |
New
|
Function: |
Wrapping
|
Application: |
Chemical,Commodity,Food,Machinery & Hardware,Medical
|
Packaging Type: |
Film
|
Packaging Material: |
Plastic
|
Automatic Grade: |
Automatic
|
Driven Type: |
Electric
|
Voltage: |
220V
|
Power: |
2.6KVA
|
Place of Origin: |
Guangdong China (Mainland)
|
Brand Name: |
TAICHUAN
|
Model Number: |
CZB-320-horizontal packing machine
|
Dimension(L*W*H): |
3770*720*1450MM
|
Certification: |
CE
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Shape of sealed bag: |
Back sealing(central sealing )
|
Packing Material: |
OPP/CPP PT/PE KOP/CPP ALU-FOIL
|
keyword: |
horizontal packing machine
|
horizontal packing machine: |
automatic
|
Material: |
carbon steel or stainless steel
|
Price Terms: |
FOB,EXW ,CIF
|
horizontal packaging machine speed:: |
high speed
|
Control: |
PLC or Double Inverter
|
All parts contacted with product: |
Stainless steel
|
Automatic flow packing machine type: |
Pillow Bag
|
