Food online > Products > Milk & Dairy Products > Other Milk & Dairy Products >

aseptic plate UHT pasteurizer,China beyond price supplier

aseptic plate UHT pasteurizer

FOB Price:Price can be negotiated

Production Capacity:5 Set/Sets per Month

Update Time:2023-04-17

Contact Supplier

Product Description

Auto plate Pasteurizer
1.juice long life product
2.hot filling juice
3.the temperature can be set on panel.
3.sus304 steel

This UHT system adopts ultra high heat treatment to sterilize the liquid dairy products, tea drink and juice for the the aseptic filling production; the sterilize temperature is 137 holding for 3~5S,by this procedure to remain the nature nutrition and FLAVOR of the milk and juice;

This machine has the following characteristics: high heat reuse efficiency, tight structure design fine looking and temperature control well etc; discharge temperature of this machine can be self controlled so it is available for the hot filling procedure and meanwhile for aseptic cold filling;

Control styles: full-automatic controlled (PLC, touch screen).

modle	LG-UHT-1	LG-UHT-2	LG-UHT-3	LG-UHT-4	LG-UHT-5
Production capacityL/H	1000	2000	3000	4000	5000
Inlet temperature	5	5	5	5	5
Holding time(s)	4-15	4-15	4-15	4-15	4-15
Sterilize temperature	105143	105143	105143	105143	105143
Product outlet temperature	20	20	20	20	20
Icewater inlet temperature	≤2	≤2	≤2	≤2	≤2
Steam pressure	0.5MPa	0.5MPa	0.5MPa	0.5 MPa	0.5 MPa
Steam consumption	150Kg/h	210Kg/h	280Kg/H	350Kg/h	420Kg/h
Compressed air pressure	0.6MPa	0.6MPa	0.6MPa	0.6MPa	0.6MPa
Compressed air consumption	50L/H	50L/H	60L/H	60L/H	70 L/H
External dimension homogenizer excluded	3500×2000×2500	3500×2000×2500	4500×2500×2200	5000×2000×2200	5000×2000×2200
Total weight of machine	1700kg	2000Kg	2200 Kg	2500Kg	2800kg

Place of Origin:	Shanghai China (Mainland)	Brand Name:	beyond	Model Number:	LG-UHT-2
Usage:	Milk	Processing Types:	Dairy Product	Processing:	Sterilizer
