drink water rinsing/filling/capping three in one Machine
No bottle no filling or capping
High speed pressure filling
MIC24-24-8C Drinking Water Washing Filling Capping three in one Machine
Filling Machine" data-width="650" ori-width="630" ori-height="473" />
This series of equipment is mainly used for a variety of polyester bottles of Mineral Water, purified water and other non-carbonated beverage production, realization washing bottle, filling and capping in one machine.
Feature
1, The machine uses the card to run bottleneck suspension design work state, so that the bottle at high speed running smoothly and reliably, while significantly reducing the number of parts to make the change when replacing the bottle more convenient and faster.
2, Using a new generation of stainless steel flip-bottle holder, and bottle screw clamp so do not touch the section above, and a nozzle, rinse the inner wall of the bottle full, no dead ends.
3, Using advanced gravity filling technology, filling fast, steady, accurate.
4, Using magnetic torque screw lid, to achieve catch cover, screw cap. Stepless torque screw cap, seal tight and reliable, and does not hurt the cover.
5, Human machine interface touch screen buttons, PLC computer control with a lack of cover, overload warning device, timely detection and troubleshooting, high degree of automation.
6, With water contact parts are made of stainless steel, the main electrical components are internationally renowned manufacturers.
Model |
Capability (bph) |
Bottle |
Cap type |
Airconsume (m3/m) |
Power (Kw) |
Weight (Kg) |
Dimensions (mm) |
||
Dia(mm) |
Height(mm) |
Capacity(ml) |
|||||||
MIC12-12-5C |
4000 |
Φ50-Φ100 |
150-320 |
330-1500 |
Plastic screw cap |
0.2 |
4.6 |
2500 |
2350*1700*2150 |
MIC18-18-6C |
8000 |
Φ50-Φ100 |
150-320 |
330-1500 |
0.4 |
5.4 |
3800 |
2350*1700*2150 |
|
MIC24-24-8C |
12000 |
Φ50-Φ100 |
150-320 |
330-1500 |
0.4 |
6.4 |
5200 |
3220*2300*2600 |
|
MIC32-32-8C |
15000 |
Φ50-Φ100 |
150-320 |
330-1500 |
0.5 |
8.07 |
6500 |
3450*2510*2710 |
|
MIC40-40-10C |
18000 |
Φ50-Φ100 |
150-320 |
330-1500 |
0.55 |
9.56 |
5000 |
3800*2800*2710 |
|
MIC60-50-15C |
20000 |
Φ50-Φ100 |
150-320 |
330-1500 |
0.6 |
11.18 |
11200 |
4510*3400*2900 |
high quality 3-in-1 mineral water bottle filling machine is packed by standard wooden cases
We will offer our technician for oversea mineral water bottle filling machine installation and training service.
We can also provide our Sales as translator to your site help the installation and Training.
Only to provide the local transportation, accommodation, air tickets (round trip) for Sales will be fine.
Thank you for choosing MICMachinery Company.
We have doing mineral water bottle filling machine for 8 years, after the company recombination, the mineral water bottle filling machine we sold to Europe, Africa, the America states and south America.
We can guarantee our mineral water bottle filling machine for years running with steady working.
We provide 8 hour action, 24hours solution after sale service, in order to avoid the time difference bring the economic and trust lost to our clients.
For mineral water bottle filling machine question:
First of all , before we operate mineral water bottle filling machine, to clearly understand the instructions clearly mineral water bottle filling machine, first read through the instructions again, adjust and use the familiar mineral water bottle filling machine, the operating time must be in strict accordance with the instructions to mineral water bottle filling machine instructions, pay attention to details of the problem , certainly the details determine success or failure .
Secondly , in accordance with the instructions on the machine for regular repair and maintenance of the mineral water bottle filling machine fuselage Oil it , so mineral water bottle filling machine body as far as possible to protect the reservoir , so that the air can be isolated to avoid wine machine rusty , well protected mineral water bottle filling machine body, and this is a way to extend the life of the 3 in1 bottling machine .
Once again , we have to pay attention to hot stand -sealing cloth for cleaning, not retained foreign body in the above , to ensure clean beverage filling machine try to avoid the amount of material for a long time into the mouth of the left cause corrosion .
Fourth , we should always check the machine to see contacts at various parts of the machine is good, important to ensure safe use of electricity, no electricity properly to prevent harm .
Fifth, if found faulty , we have to turn off the power , when necessary, by pressing the emergency stop button , and then deflated lift cover, and then close the voltage , check the reason
Type: |
Filling Machine
|
Condition: |
New
|
Application: |
Beverage,Beverage and water
|
Packaging Type: |
Bottles
|
Packaging Material: |
Plastic
|
Automatic Grade: |
Automatic
|
Driven Type: |
Electric
|
Voltage: |
380v
|
Power: |
6.4kw
|
Brand Name: |
MIC
|
Model Number: |
MIC24-24-8C
|
Dimension(L*W*H): |
3220*2300*2600mm
|
Weight: |
5200kg
|
Certification: |
CE
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
Name: |
drink water rinsing/filling/capping three in one Machine
|
Capacity: |
330-1500ml
|
Airconsume: |
0.4(m3/m)
|
Capability: |
12000bph
|
Processing: |
Filling Machine
|
