cocoa with sugar lab Spray Dryer LPG-5

Cocoa with sugar Lab Spray Dryer is used to laboratory production of micro-particle powder by universities, research center and food, biotechnology.

Application:

Cocoa with sugar Lab Spray Dryer is used to laboratory production of micro-particle powder by universities, research center and food, biotechnology, beverage, chemical, material, and pharmaceutical enterprise lab.

This method is suitable for the dry process of all solutions including emulsion, suspension, etc ( Organic liquid is forbidden ). of heat-sensitive materials, such as biological products, bio-pesticide, and enzyme etc. Because only mist size of particle sprayed by machine can get high temperature and the particle is transient heated to keep the active ingredient of those active material undamaged after drying process.

Features :

l         Special for lab research, Min 20-30ml liquid to finish one test;

l         All borosilicate glass for easy visual monitoring of process status;

l         Spray chamber, cyclone separator, receiving tank are all made of Borosilicate glass which can resist strong acid/alkali, high temperature. It can work in a no-pollution and stable environment;

l         Easy to clean and very simple to assemble and break down;

l         The air compressor is no oil and don’t pollute compress air. The sound is low than 50db and following the GMP understands;

l         Inlet/outlet temperature is accurate controlled by PID;

l         The unit is self contained and supplied complete and ready for immediate operation;

l         Using screen touchable face display operation, control temperature, airflow volume, air pressure, pump speed and de-blocker frequency;

l         Product feeding with RS2559605 rotary pump, capacity is adjustable;

l         Automatic de-blocking device prevents the nozzle from becoming blocked and variably controlled.

Key Specifications :

l         Max capacity                    1500ml/h

l         Temperature range of inlet air       30°C~280°C

l         Temperature range of outlet air      30°C~120°C

l         Temperature precision             ±1°C

l         Speed of squirmy pump            30~1500ml/h

l         Electric Heater                    AC 220V, 3KW, single-phase, earthed

l         Blower                          Power: 0.1KW

Max consume of air: 330m ³ /h

Max air pressure: 686Pa

l         Air compressor                   Power: 0.25KW

                                    Max consume of air: 4.2m ³ /h

                                    Working air pressure: 0.2~0.5Mpa

l         Atomizer                        Standard 0.75mm jet

l         Pressure of the needle              0.3MPa (adjustable)

l         Pressure of spraying               0.25~0.3MPa (adjustable)

l         Power supply                    200~230V, 3.5KW

l         Dimensions                      700×600×1550 mm ( L×W×H )

l         Weight                          120kg
