Coil Type UHT instant sterilizer,China CNZH price supplier

Coil Type UHT instant sterilizer

FOB Price:Price can be negotiated

Production Capacity:100 Set/Sets per Month

Update Time:2014-09-19

Contact Supplier

Product Description

Coil type UHT instant sterilizer
Handling capacity: 1-4t/h
Sterilization temperature: 115~145 centi grd
Holding time: 4~6s

Description

Coil type UHT instant sterilization equipment

UHT sterilizer adopt heat exchanger with coil structure. Short Material heating time assure small nutrition loss of food. It is widely used in sterilization of fresh milk, sauce, beverege, wine, etc.

Main parts

Material pump, balance barrel, heater, coil type heat exchanger, Temperature controller and recorder, electric control system

Parameters

Model	SG-UHT-1/S SG-UHT-1/Z	SG-UHT-2/S SG-UHT-2/Z	SG-UHT-4/S SG-UHT-4/Z
Handling capacity t/h	07~1	1.5~2	3.5-4
Outlet temperature of materials °C	<65	<65	<65
Sterilization temperature °C	115~145	115~145	115~145
Holding timr s	4~6	4~6	4~6
Inlet pressure of steam Mpa	≈0.8	≈0.8	≈0.8
Steam consumption Kg	0.15	0.15	0.15
Power Kw	2.2	3	4(6)
External dimension (L x W x H	1314 X 925 X 1650	1500 X 1050 X 1800	1750 X 1350X 2000

Condition:	New	Place of Origin:	Zhejiang China (Mainland)	Brand Name:	CNZH
Usage:	Milk/Juice/Beer	Warranty:	2 Years	After-sales Service Provided:	Engineers available to service machinery overseas

Other Products

Turnkey Dairy Production Line

UHT Pasteurizer Machine

Tubular UHT sterilizer

Coil Type UHT instant sterilizer

Company Profile

Name: CNZH Technology Co., Ltd.

Main Products: Biopharmaceutical Machinery,F&B Processing line,Dairy brewery equipments,Condiments equipments,Fine chemical equipments

Business Type: Manufacturer, Trading Company

Total Employees: 501 - 1000 People

Established Year: 2009

Main Markets: Western Europe, Eastern Asia, Mid East, Oceania, Africa

Address: No. 2551, Yongqiang Avenue, Wenzhou City, Zhejiang Province. China

CNZH Group, headquartered in WENZHOU, China, is a leading combined group with 3 companies on mechanical engineering especially food and liquid process engineering and equipment.
CNZH Group technologies are applied in the food, dairy, winery and brewery, beverage, condiments, biochemical as well as the pharmaceutical industries.

Wenzhou Tianyu Light Industrial Machinery Co., Ltd
Jiangsu Tianyu Machinery Co., Ltd
Shanghai Haoyu Machinery Co., Ltd

Main Industry solution service:
Dairy Engineering: Pasterilizeed milk, UHT milk, yoghurt, etc
Beverage Engineering: Vegetable, fruit juice, tea, functional beverage etc
Condiments Engineering: Ingredient of sea food, bone, vinegar etc
Pharmaceutical Engineering: Herb, injection, biochemical, pet,
Food Engineering: Cans, agricultural byproduct,
Fine Biochemical & Biological Engineering: Essence, tea polyphenols, enzyme preparations.
served for most of the well-known food group and company, excellent product quality, credit and reputation.
Service:
Turnkey production line solution
food machine solution
Production line design,
Machine fabrication and supply,
Engineering installation,
Commissioning,
After-service maintains and support

Famous Customers
Mars(Dubai), DuPont, Coca-Cola, Pepsi, Robust(milk), Bosch(machine),
Yili(milk), Mengniu(milk), Guangming(milk), huiyuan(juice), Wahaha(milk), Kanshifu(machine), Huiyuan, Wahaha, Nongfu spring water, Taizhinai(milk beverage), zhejiang panda dairy(milk), etc

Advanced machines for stainless steel machine fabrication,
CNC machines processing, regulated QC control system and testing system and equipments(X-ray test gun, testing machines and examine machines etc ), ensured the product in high quality.
Certification:
Qualified ISO9001 and HACCP certification,
Pressure vessel certificated GB150.
ASME certification from third party authentication for export. more
