Disk Stripping Tester BLJ-01 is professionally used to test ink fastness of plastic films and glass paper decorating printed materials that utilize the intaglio printing technique. Disk stripping tester could also be used to test adhesion condition of surface layers formed by the techniques of vacuum coating,surface coating and lamination.
Disk Stripping Tester BLJ-01
Test principle
The standard glass adhesive tape should be bonded together with ink printing surface, which is pretreated according to test conditions, by adhesive tape roller under specified load, rolling speed and rolling times. After a certain contacting time, separate them by disk stripping tester at certain pressure and peeling speed. The ink fastness property could be obtained by observing the ink layer peeling conditions.
Application
Product
|
Name
|
Application
|
|
Vacuum aluminum paper
|
Disk stripping tester test layer attached state for vacuum aluminum paper
|
|
Printed products
|
Test fastness to printing ink layer for printed products
|
|
Electrode slice
|
It is used for test stripping force for electrode slice
|
|
Plastic color printing
|
Test printing ink layer fastness for plastic color printing products
|
Technical feature
★Disk stripping tester is controlled by micro-computer, with PVC operation panel, which is convenient for users to operate
★Automatic alarm reminding for safe operation when the test is finished
Main Specification
Technical parameter
|
|
Pressure Between the Plate
|
100N
|
Stripping Speed
|
0.8 m/s
|
Dimension
|
290mm×240mm×390mm
|
Net Weight
|
20kg
|
Environment requirements
|
|
Environment temperature
|
15℃-50℃
|
Relative humidity
|
No more than 80%,no dewdrop
|
Power supply
|
220V,50Hz
|
Standards
JIS C2107,JIS C2107,GB/T7707
Configuration
Disk stripping tester host, Power Line
