meat grinding machine
1.easy operation
2.high quality and efficiency
3.factory price
4.material:stainless steel
Multi-function Meat Precessing Machine/Meat Grinding Machine
Feature of meat grinding machine:
1.Meat Grinder depend on the screw pushing the original meat in hopper to the pre-cut board, Then depend on the relative moving between screw's rotating & pressing and rimer to cut the original meat into granular size. By this way can also keep the uniformity of meat.
2.The Meat Grinder design both clockwise and anticlockwise,Then the machine could never block the machine
3.You can assemble the different pole plate to match different requirements of meat size.
Technical data of meat grinding machine:
Name | Meat grinding Machine |
||
Capacity (kg/h) |
300-500 |
1000-2000 |
5000-10000 |
Power (kW) |
5.5 |
9/11 |
37 |
Hole Plate (mm) |
φ4/φ6/φ8/φ12 φ18/φ25/φ35 |
φ3/φ5/φ7/φ10 φ13φ20/φ25 φ30/φ35 |
φ4/φ6/φ8/φ10 φ13/φ16/φ23 φ28/φ35 |
Worm Speed(rpm) |
336 |
106/160 |
150 |
Meat Temp. ( o C) |
-2-0 degree |
-5-0 degree |
-10-0 degree |
External Dimension(mm) |
850×570×1000 |
1350×750×1150 |
2070×1070×1685 |
Installation Dimension(mm) |
1500×1000×2000 |
2000×1500×2000 |
3000×1800×2500 |
Weight(kg) |
approx. 350 |
approx. 400 |
approx. 1500 |
Picture show the meat grinding machine:
The details:
Different models:
The packing of meat grinding machine:
Shipping of meat grinding machine:
1.Passionater Salemen help you to well know our products and company
2.Experienced engineer and workers produce your orders
3.Professional inspector check Rides Quality before delievery
4.Excellent technician guide Rides Assemble at your place
5.Creative Designers Programme your indoor or outdoor site, and design Customized Ride
according to your demand.
1. What's best way of cleaning and maintenance for cutting?
Answer: Because this series of machine is processing machine that exist oil, can use boiling water clean cutter , you can also add detergent properly to clean it.
Cutters maintenance: After cleaning the cutter, you should oil edible oil after drying it, which can make it lubricating and antioxidant.
2. What's the maintenance about machines?
Answer: Maintenance method: Machine should add lubricating oil aiming at chain, gear and bearing every half year, reduction gearbox should be added engine oil. If the machine was used frequently, we suggest that you can maintain it once every quarter. If the machine along with belt, conveyer belt, spring, you should check them whether loose every quarter, adjust or change them in time when were found loosely.
3.What can we do if the cutter is blunt or oxidized with yellow?
Answer: Cutter is blunt, you need to use the emery cutter or the abrasive stick to polish it.If the cutter is oxidized with yellow, use YiJieling or other scouring liquids to polish it ,and use edible oil for protection after cleaning.
4.How mang hours can the machine work continuously?
Answer: Machine can work 24hours continuously in general condition. But suggest open it after 4-5hours you should hold on, which provide certain protection for machine.
5.How to purchase meat Cutting Machine, why price difference exist so big?
Answer: Meat cutting machine can cut fresh meat, cooked meat ,frozen meet and bone .You should according to properties of meat and their output when buying machine. For some high price, equip with Magnetic control protection witch, cutter is convenient for cleaning, perfect cutting, excellent materials for blade etc.
6.Can the outing-mold of patty machine and ball forming machine order ?
Answer: Equip with appointed specifications for original configuration, Order other size mold within match size ,required to be add fare of mold , ball forming mold is ordered no more than 28MM
7.What's the characteristic s of four thawed machine?
Answer: Recirculating Water Thawing Machine adopt the high pressure flowing water to thaw the material. Spraying Thawing Machine thaw material according to water circulation system and powerful spraying system. Water-cooling Pneumatic Thawing Machine through heating exchange of flowing water, Compression hot air and heating strip. Wind-Cooled Thaw Machine internally installed air-heater, achieving thawing effect through air flowing.
Thank you for taking the time to visit our website . Any colors, any logo accetpable, we can offer smaple to you, Pls leave an inquiry to know more details about Price, Packing , Shipping and Discount. Explore for more product information.
Place of Origin: |
Henan China (Mainland)
|
Brand Name: |
Qixin
|
Model Number: |
MGJ01
|
Type: |
Meat Processing Machinery
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
machine type: |
meat grinding machine
|
voltage: |
110v/220v/380v
|
power: |
5.5kw
|
capacity: |
300kg/h
|
certification: |
ce
|
speed of rimer: |
336r/min
|
material: |
stainless steel
|
rimer size: |
different size
|
meat type: |
fresh or frozen
|
packing: |
carton box
|
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
