ND-4 Internal Combustion rail Tamping machine,China price supplier

ND-4 Internal Combustion rail Tamping machine,Tamping machine

Product Introduction chinacoal05

 Internal combustion tamping picks a small road suitable for railway track maintenance machinery, mainly used for ballast track tamping homework. Its novel design, compact structure, is a kind of way rapidly up and down, stamping equipment, convenient operation is particularly suited to switch tamping homework.

This machine is mainly composed of gasoline engine, the vibration damping device, a transmission axis, a vibration body and hand, constitute a complete independence of handheld tamping machine, neither the long cables, no heavy soft shaft, compact and reasonable structure, easy to use.

Main Parameter

 ND-4 Internal Combustion Tamping Tool

a. petrol engine power: 1.42kw

b. vibrating force: ≥ 4.2KN

c. idling amplitude: ≥ 5mm

d. frequency: 120~140HZ

e. diameter of vibrating & tamping bar: 52mm

f. rev. speed of eccentric block: 7000-8000r/min

g. total weight: 16kg
