Noodle machine made in china, factoryautomatic noodle machine
1 All-steel gear
2 stainless steel
3 CE
noodle machine made in china
Automatic noodle machine with perfect technology, compact structure, original design and stable performance. It realizes high automation, convenient operation, and low energy consumption. All working procedures from feeding flour to finished products can be accomplished automatically. Over decades years, we are dedicated to our customers with quality product and service, while continuously look for improvement and innovations in our noodle-making technology. Our noodle machines have reached places around the world, including Asia, Europe, Arica and America.
We provides our customer with machines of "High Performance, Easy Operation, and Minimum Maintenance Requirement", while satisfying the need for our client to reduce energy consumption and labor cost, and meeting the strict hygiene requirement for food production industry. For mechanical parts, molds are used for fabrication to reduce the amount of welding. It gives the equipment the advantage of easier maintenance, better hygiene condition and also gives a better appearance. From raw materials to fabrication, assembly, and installation on site, in each process we strive for accuracy and quality. We are also very serious about the safety features of our machine, and had received CE certificate.
Features about the noodle making machine
The grinding Roller of the automatic noodle machine has been grinded finely, smooth and beautiful, the dough after rolling is smooth and bright, to ensure a good quality noodles. Driven with speed reducer and chain driving, the layout of the whole machine is properly, rational distribution, smooth transmission, accurate and efficient power of janitor's room, as well as low noise, no vibration, superior performance. The machine is small, compact, safe to operate, simple operation, easy maintenance. The machine can make regular, equal thick and thin noodle. They are the good helper of modem families.
1. Equipped with the chilled hard alloy which the hardness can reach HRC49-54, That makes the roller can press the best quality flour slice, at the same time ensure a longer service life.
2. Worm gear pairs are equipped between the rollers, it will be more easy in operation, high precison and efficiency. Pressing process controlled by the frequency control and the rollers can run independently. The noodle making system is processed horizontally which will save the labor and money for you don’t need to built a tall workshop.
3. Our noodle processing line is advanced, highly automatic. Through pressing to cutting process, The whole process controlled by the frequency control devices.
4. The working line is reliable, safe, easy maintenance, high efficiency, energy-saving, environment-friendly and healthy. You can make good quality noodle in any climate conditions.
5. It changed the traditional vertical structure.It needn't to elevate the flour to the stirring machine and curing machine upstairs,this change save1-2 workers and reduce the more than 50% labor intensity.It also saves space and a set of hoisting equipment.
6. The bloom roller and the composite roller is made by steel and the smoothing roller is made by alloy.
7. This machine is assembling a set of automatic noodle lifting equipment for free.
8. Automatic hanging-up machine of the stick noodles production line. The length of the noodle can be adjusted, no break on pole, no falling pole, no accident.
9. Stainless steel sheet roller,and it can produce varies of noodles ( dry noodles, grain noodles, vegetables nutrition noodles, various colors noodles )
Technical parameters about the noodle making machine
Model |
MT7-300-1 |
MT7-300-2 |
Roller Size |
φ138*300 |
φ138*280
|
Roll ed slice of t hickness |
≥0. 5 |
≥0.4
|
Output |
300 KG/H |
280KG/H |
Power |
4Kw |
4Kw |
Weight |
900 Kg |
1000Kg |
Size |
2800 *720*1350MM |
2800 *720*1350MM
|
noodle machine
noodle machine details
noodle machine
noodle machine
noodle machine parts
our factory
Installation Description about the noodle making machine
1. The automatic noodle machine must be flat and stable on the floor when fixed it. Opening the side cover and filling 30# machine oil to the reduction gears. Grounding lines according to the ground signs.
2. Check fasteners to see if there is any one become loose after the transportation.
3. Plug the power, test the positive and negative going motion. In normal cases, install the triangular belt and motor shield.
4. Check every oil hole to see if it is clear. After filling oil, and then start the machine.
The operation process about the noodle making machine
satisfied services
1. Help you choose the most suitable model.
2. Making the machine according to your request.
3. Supply machine’s information and v ide os for help you operate the machine more efficent.
4. Supply One year warranty.
5. If any q uality problem,we will send you the accessori es as soon as possible.
6. Free repair whole using life without extra charge.
Condition: |
New
|
Type: |
Noodle
|
Production Capacity: |
300kg/hour
|
Place of Origin: |
Hebei China (Mainland)
|
Brand Name: |
Judu
|
Model Number: |
MT7-300-1
|
Voltage: |
380V
|
Power(W): |
4kw
|
Dimension(L*W*H): |
2800mm*720mm*1350mm
|
Weight: |
900kg
|
Certification: |
CE
|
Warranty: |
1 year
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
the thickness of rolled flour slice: |
greater than or equal to 0.5mm
|
capacity: |
300kg/hour
|
power: |
4kw
|
oversize: |
2800mm*720mm*1350mm
|
applications: |
making dry/wet noodles
|
port: |
Tianjin port
|
roller size: |
dia138*300
|
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
