Plate type high temperature sterilizing equipment,China DF price supplier

Plate type high temperature sterilizing equipment

FOB Price:Price can be negotiated

Production Capacity:20 Set/Sets per Month

Payment Terms: US $0 - 50,000 / Set

Update Time:2021-12-13

Contact Supplier

Product Description

Beverage steurilizer unit
1.Material:SUS304
2.It is an ideal equipment for liquid food pasteurizing,milk,Juice,dairy,beverag

Beverage steurilizer unit
1.used for Sterilization for milk, juice and Ice cream etc.
2.the temperature can be set by .

Technical Parameter of plate pasteurizer:

5→65(homogenization)→85(15S) →5

Model	size	steam consume	steam pressure	ice water consume	ice water flow	electrical power	outside measure	weight	pipe size
Model	t/h	kg/h	bar	Kca/h	t/h	kw	lwh	kg	material	steam	medium
BR16-PUT-SN-1t	1	40/76	4.0	20,000	3	3.0	1.61.41.8	730	32	DN25	32
BR26-PUT-SN-2t	2	80/152	4.0	40,000	6	4	1.61.41.8	910	32	DN25	32
BR26-PUT-SN-3t	3	120/228	4.0	60,000	9	4	1.81.62.0	940	38	DN25	38
BR26-PUT-SN-4t	4	160/304	4.0	80,000	12	6	2.01.62.0	970	38	DN32	51
BR26-PUT-SN-5t	5	200/380	4.0	100,000	15	6	2.21.62.0	1030	51	DN32	51

Production capacity: 500L-20T/H

This unit can be connected with separator, homogenizer, flash evaporator & degasser etc. This unit is used as Pasteurizer (widely used in fresh milk, milk beverage, juice, tea, alcohol, ice cream etc.), and also pre-sterilize material when producing Pasteurized milk (long life milk).

This machine has features of high heat recovery, lower energy cost, strict design on the construction and easy operation, simple maintenance.

Control type: Full-automatic control (PLC with touch screen), semi automatic.

Standard attachments:

A. plate heat exchanger; B. material-balance bucket;

C. hot water-balance drum; D. hot water pump; E. product pump;

F. steam & water mixer; G. electricity box;

H. stainless steel pipes and valves etc . I.PLC and color touch screen or PID

Place of Origin:	Zhejiang China (Mainland)	Brand Name:	DF	Model Number:	UHT(Pasteurizer set)
Usage:	Fruit & Vegetable	Type:	Ultra High Temperature	material:	stainless steel
process:	high temperature sterilizing equipment	capacity:	500L-20T/H
