ultrasonic processor disruptor,China Banry price supplier

  Ultrasonic sonochemistry biodiesel processor system

ultrasonic  processor disruptor

  MODEL:  BR-28SH/BR-20SH

  INTRODUCTION:

The ultrasonic sonochemistry biodiesel processor system is composed of ultrasonic transducer (converter) with cover,booster, horn (sonotrode, probe) and generator.

This ultrasonic energy not only to promote or stimulate a number of chemical reactions, speed up the chemical reaction speed, even some of the chemical reaction can change the direction of some unexpected results and a miracle. This is the sonochemistry. Sonochemistry can be applied to almost all chemical reactions, such as separation and extraction, synthesis and degradation, bio-diesel production, Governance of micro-organisms, the degradation of toxic Organic pollutants, deal with biodegradable, biological cells crushed, and Dispersed and cohesion, homogenizing,milling,disintegration,emulsifying,extraction and so on.

Hangzhou Banry Ultrasonic Focus on the domestic first high-power ultrasonic probe ultrasonic sonochemistry processing equipment. Does not change a customer's existing production equipment and technological process, through a simple installation can be your ordinary equipment upgrades for the chemical industry with the advanced ultrasound equipment. Ultrasonic high-power, and low investment, simple installation, output and efficiency was improved.

Ultrasonic technology has a prominent advantages, that is, it does not have moving parts, there is no electromagnetic radiation, is simple to install fixed, in particular for the high-pressure high-temperature, toxic, explosive or dangerous environment for the application.

Sonochemistry processing system is another application in sewage treatment and cleaning the area of anti-scaling. Many experts and scholars have done a substantial amount of research experiments to prove the ultrasound equipment and pipeline cleaning side fruitful. Ultrasonic cleaning equipment, low power consumption scale, to adapt to a wide, easy to install, equipment almost do not need any modification.

MAIN ADVANTAGE:

  1. Optional frequency and power , 40kHz — 20 kHz, 200W - 3000W.

 2. With over current , overvoltage protection, to ensure system security .

  3. Frequency automatic tracking adjustment , to avoid the load impedance with the ambient      temperature , the  working medium due to factors such as changes in the larger power fluctuations.

  4. Constant power, good effect.

  5. Ultrasonic digital generator, small size, light weight and high efficiency .

  6. Reasonable structure , easy ventilation , continuous running and reliable operation .

    Modular design , can be by several hundred watts or several kilowatts of power to form tens kilowatts generator , which can optimize the combination of the transducer , and then ensure transducer work in the best condition ; such as a generator fails, the other unit still work, easy to repair the damaged unit.

SPECIFICATION:

APPLICATION:

 Mainly used in extraction of oil, biodiesel , natural pigment, Polysaccharide, flavonoids, alkaloids, polyphenols, organic acids, the composition,fat. Ultrasonic cell crushing, to extract essential oil, natural pigment extraction, the polysaccharide extraction, extraction, alkaloids extracted flavonoids, polyphenols extraction, organic acid extraction, oil extraction, Chinese medicine extract and so on.

.

                                 Ultrasonic processing is the left one.

DRAWING :

  PACKAGING:

DELIVERY TIME : 15DAYS

PAYMENT TERMS : T/T,L/C,ESCROW

GUARANTEE: one year for whole equipment warranty. Equipment for the warranty, please contact us first. We will immediately feedback how to return repair.

  FAQ:

  1. Do you have it in stock?

   Sorry, haven’t.

  2. Could you supply sample?

    Sorry, we can't supply sample for free, because its value is high.

  3. Could you make it according to our special requirements?

   Of course, we can do. Please tell us your idea or your application.

  4. How long do you make the order product?

   About 20days

  5. Do you have operating manual?

   Of course, we will put it with the goods together.

  6. How about the quality?

   One time business is not our target, we hope to be as one hundred enterprises.

  7. Could you do OEM/ODM ?

    Yes, of course.

  8. Could we as your agent?

    Of course, it’s our pleasure.

Requirements:

1. Need to know ultrasonic knowledge

2. Has a good business reputation.

  3. Have certain economic strength.

  4. Strong ability of management.

  5. Have a sound sales network (with the ability to expand the market).

  6. Agents need to implement the unified national price policy of our company, may set the sale price of do STH without authorization, shall not be string.
