Auger Dosing Machine (Bench Top Unit) , cocoa powder Auger Filling Machine,50L,China JENPACK price supplier

Auger Dosing Machine (Bench Top Unit) , cocoa powder Auger Filling Machine,50L

FOB Price:Price can be negotiated

Production Capacity:25 Set/Sets per Month

Update Time:2023-11-27

Contact Supplier

Product Description

1:Auger Filling Driven by servo system.
2:Filled by auger revolutions.
3:Auger filler integrated with bagging unit.
.

Descriptive abstract
This type can do measuring and filling work. Due to the special professional design, it is suitable for the fluidic or low-fluidity materials, like milk powder, Albumen powder, rice powder, Coffee powder, solid drink, condiment, white sugar, dextrose, food additive, fodder, pharmaceuticals, agriculture pesticide, and so on .

Technical data

Model	JN-3B-100	JN-3B-500	JN-3B-600
Hopper	Quick disconnecting 50L	Split hopper 50L	Split hopper 65L
Packing weight	10 ~ 2000g	10 ~ 2000g	10g ~ 5kg
Packing Accuracy	<100g, <±2%;100 ~ 500g, <±1%; > 500g , <±0.5%	<100g,<±2%;100 ~ 500g, <±1%; > 500g , <±0.5%	<100g, <±2%;100 ~ 500g, <±1%; > 500g , <±0.5%
Filling speed	40 ~ 120 times per min	40 ~ 120 times per min	40 ~ 120 times per min
Power supply	3P AC208V ~ 415V 50/60Hz	3P AC208V ~ 415V 50/60Hz	3P AC208V ~ 415V 50/60Hz
Total power	1.9Kw	1.9Kw	2.4Kw
Total Weight	200kg	220kg	250kg
Overall Dimension	1060×600×1100mm	1060×650×1100mm	1125×700×1200mm

Main features
The hopper could be washed easily without tools.
Servo motor drive screw.
Stainless steel structure
Include handwheel of adjustable height.
Replacing the auger parts, it is suitable for material from super thin powder to granule.

Filling Machine,50L" ori-width="247" ori-height="396" />

Type:	Filling Machine	Condition:	New	Application:	Food,Medical,Chemical
Packaging Type:	Cans,Bottles,Bags	Packaging Material:	Metal	Automatic Grade:	Semi-Automatic
Driven Type:	Electric	Voltage:	3PAC208V-415V	Power:	1.9KW
Place of Origin:	Shanghai China (Mainland)	Brand Name:	JENPACK	Model Number:	JN--3B-500
Dimension(LWH):	1060x650x1100mm	Weight:	220kg	Certification:	CE
After-sales Service Provided:	Engineers available to service machinery overseas
