filter nozzle,nozzle strainer,filter strainer,China haixing price supplier

filter nozzle,nozzle strainer,filter strainer

FOB Price:Price can be negotiated

Production Capacity:2000

Payment Terms: FOB CIF CFR

Update Time:2025-07-14

Contact Supplier

Product Description

Haixing-filter Nozzles, manufactured uniquely in stainless steel or alloy, are successfully used in mixed beds, ion exchangers and regenerators of condensate polishing system.

The wedge wire element in a nozzle is a screen pipe. Nozzles are closed on one side and have a threaded fitting on the other. One rubber shim , one steel shim and two thin nuts of the same material for a nozzle. Material: SUS304, 1Cr18Ni9Ti, AISI316L, 316 and Haynes alloy C etc..

Nozzles can be used for liquid/solid or gas/solid separation, or media retention (sand, catalyst, resin, ....).The nozzles are mounted on a support plate. The dimensions and the distribution of the nozzles on the support plate can be altered to obtain an optimized flow distribution.

Above mentioned designs are used widely in down-flow reactors for liquid/solid or gas/solid separation. The liquid or gas can flow through the nozzles while the solids are retained in the vessel by the nozzles.

·high strength compared to plastic nozzles

·flexibility in design

·strong construction (self supporting)

·large open area

·plug-resistant slot design

Other Products

filter nozzle,nozzle strainer,filter strainer

header lateral,hub lateral,collector

resin traps

sieve bend screen,flat panel screen,V-shape profile wire screen

Company Profile

Name: Haixing wedgewires filter company

Main Products: filter nozzle,header lateral,hub lateral,resin traps,wedge wire screen,water well screen,steel casing pipe

Business Type: Manufacture

Total Employees: < 20

Address: number2589 west shengli road

Haixing wedgewires filter Company is known world-wide as a manufacturer of high quality Stainless wedge wire screens for the Water Intake and Waste Water, Fish Diversion and Hatchery, Petrochemical, Pulp and Paper,??Food and Beverage, and the Mining and Aggregate industries.??We also produce up-market, exotic, profile wire surfaces for Architectural uses; both functional and decorative.??Our customers number in the thousands in over 35 countries, and we list many Fortune 500 and international companies as long-term customers.
