Working principle:
A sucking nozzle sucks transfers the pre-printed and cut paper from the paper shelf to the feeding chains and then the paper is carried to shaping moulds, during which the paper is glued thermo sol. The position, length and quantity can be adjusted while in progress without stopping production. The shaped paper is discharged to collector and is piled and counted automatically. The preset piling quantity of paper is carried forward automatically when it is finished without stopping production.
The Specifications of the product DYK6-B produces
1. Minimum height:100mm
2. Maximum height: 255mm
3. Angle: 15°-28° (different size products can be made with an adapted die)
Characteristics
● High efficiency: Continuous production in three shifts and finished products are counted automatically;
●The system is computerize numerically controlled systerm, touch screen control panel and thus operation is more easy and maintenance is saving.
● High precision parts: More endurable and longer service life.
● Intellectual detection: Safety protection is further strengthened and faults can be detected automatically and indicated on line.
● Main facility is lubricated in oil cycle and thus components is more durable.
● Design philosophy: High speed, high efficiency, energy saving and safe.
● Thermo sol-spraying mode: Adopt digital information input and data can be replaced without stopping the machine.
●Inexpensive.
Production speed:
Produce as many as 220 pcs per minute.
Raw materials:
Common paper, aluminum foil paper or dry wax paper which is not exceeding 100g/m2.
Covering area: 2.5M × 2.5M
Package dimensions: (1) Length: 1.50m Width: 1.20m Height: 1.50m
(2) Length: 1.43m Width: 0.71m Height: 1.12m
Weight: Gross weight 1200kgs approx.
Points of considerations:
● use machine of compressed air without drying may reduced service life of components and destroy the machine.
● Erroneous selection of materials (including papers and thermo sol) may debase the efficiency and bring the problem of quality.
● The printing of logo and treat with surface of papers is very important and must to test the papers before use. Wrong operation may caused quality problem and reduce efficiency.
Zhongshan Dayuan Industrial Co., Ltd is a professional supplier of eco-friendly paper processing machines, following the enterprise development mission “Create Value for Customers”. Founded in 1995, the company is located at Zhongshan, Guangdong, the hometown of Sun Yat Sen.
At the beginning of 1990s, the production of snack boxes (such as ice cream paper cone, hamburger box, etc) mainly relies on manual operation or machines imported from European and American countries. The poor sanitation condition and product consistency, low efficiency, expensive imported machines, long delivery period and high service cost all restricts the development of domestic paper production enterprises. With rapid development of Chinese national industry, Dayuan determinedly enters this completely new industry.
As one of the companies that first engage in self-innovative development of eco-friendly paper processing machines in China, Dayuan has won extensive acknowledgment and praise from the start to development and from China to the world. Now, it has become a leading supplier of eco-friendly paper processing machines in China.
With oven ten years’ exploration and development, the sales volume of four series self-innovative products (Ice Cream Paper Cone Machine ，Carton Erecting Machine, Paper Cone Cup Machine and Automatic Punching Machine) rank first in the domestic market, the products have also exported to more than thirty countries and are favorably reviewed by domestic and overseas customers. Currently, The Paper Cone Cup which produced with DaYuan Paper Cone Cup Machine has been tested and accepted by relevant national health departments. Now, It has been launched on the market and widely used in major airports and public places, such as Shanghai Expo, Shanghai Pudong International Airport and Hongqiao Airport and some hospitals.
Dayuan staff’s unwearied pursuit to product technology and persistent feeling to the national industry prove that China is capable of developing and manufacturing its own paper processing machines. Dayuan designs and manufactures each product according to European standard and it is an enterprise that produces high-grade paper processing machines with the highest efficiency, most complete auxiliary equipments and most sales volume in the industry.
By inheriting the operation concept of “Continuous Innovation, People-oriented”, adhering to the enterprise objective of “Honest Operation, Effective Service” and taking “Eco-friendly, Highly Effective, Stable, Quality Creates Value” as product development concept, Dayuan will keep on going steadily.
