Automatic Ball lollipop Packaging Machine
1.PLC control
2.Output:1000-2000kg/8h
3.Touch screen
4.CE certificate
YB-350 Automatic Ball Lollipop Packaging Machine
Features:
1. This machine is mainly composed of automatic sorting device, packing paper color code auto tracking system, standard tongs, lollipop conveyer chain, paper packing device, packing knot, rotating plate device, and heat sealing knotting device.
2. With state-of-art technology, stable performance, and high performance cost rate, this machine not only could reduce labor cost, but also could increase the sanitary standard and packing quality of candy, which could considerably increase the production efficiency of the enterprise.
3. The color code tracking system of trademark corrector is controlled by microcomputer, and featured with correct and reliable operation, coordinated acting on paper feeding, wrapping paper, heat sealing, knotting etc.
4. This machine is good looking, neat and good sealing. The electric control system is equipped with photoelectric tracing circuit. When there is no candy at the start of the machine, the paper would stop at same time so that no paper is wasted.
5.PLC control,color touch screen.
Machine photo:
Technical parameter:
Power of main motor |
0.75kw 380v |
Power of brushing motor |
4×60w 380v |
Power of paper feeding motor |
0.2kw 220v |
Heating sealing pipe |
0.15kw×6 24v |
Air pressure |
0.2-0.5Mpa |
Output (According to standard shape candy) |
1000-2000kg/8h |
External dimensions (mm) |
2500×900×1500 |
Weight (kg) |
1200 |
Our factory:
Welcome to your inquiry!
Type: |
Other
|
Condition: |
New
|
Application: |
Food
|
Packaging Type: |
roll film
|
Packaging Material: |
Wood
|
Automatic Grade: |
Automatic
|
Driven Type: |
Electric
|
Voltage: |
220V
|
Power: |
2.5KW
|
Place of Origin: |
Shanghai China (Mainland)
|
Brand Name: |
YB
|
Model Number: |
YB-350
|
Weight: |
1200kg
|
Dimension(L*W*H): |
2500*900*1500mm
|
Certification: |
CE
|
After-sales Service Provided: |
Engineers available to service machinery overseas
|
packing speed: |
1000-2000kg/8h
|
controller: |
PLC
|
warranty: |
1 year
|
certificate: |
CE
|
power of main motor: |
0.75kw 380v
|
machine body: |
stoving varnish/stainless steel
|
power of brushing motor: |
4*60w 380v
|
language: |
English
|
air pressure: |
0.2-0.5Mpa
|
weight (kg): |
1200
|
