fully-automatic milk pasteurizer,China BEYOND price supplier

fully-automatic milk pasteurizer

FOB Price:Price can be negotiated

Production Capacity:5 Set/Sets per Month

Update Time:2014-09-18

Contact Supplier

Product Description

Milk pasteurizer:
1.pasteurization
2.fully auto control
3.seimens PLC and touch screen
4.UK sprirax sarco steam valves

Technical Parameter of milk pasteurizer:

5→65(homogenization)→85(15S) →5

Production capacity: 500L-10T/H

This unit can be connected with separator, homogenizer, flash evaporator & degasser etc. This unit is used as Pasteurizer (widely used in fresh milk, milk beverage, juice, tea, alcohol, Ice cream etc.), and also pre-sterilize material when producing Pasteurized milk (long life milk).

This machine has features of high heat recovery, lower energy cost, strict design on the construction and easy operation, simple maintenance.

Control type: Full-automatic control (PLC with touch screen), semi automatic.

Standard attachments:

A. plate heat exchanger; B. material-balance bucket;

C. hot water-balance drum; D. hot water pump; E. product pump;

F. steam & water mixer; G. electricity box;

H. stainless steel pipes and valves etc . I.PLC and color touch screen;

		(m²)	(kw)	(kg/h)	(××)mm	(kg)
BR16-BS-0.5	0.5	5	5.2	52	1200×1200×1500	790
BR16-BS-1	1	8	5.2	60	1500×1500×1800	880
BR16-BS-2	2 t/h	13	6	104	1800×2000×1800	980
BR26-BS-3	3 t/h	20	6	156	2000×2000×2200	1080
BR26-BS-4-5	4-5 t/h	30-45	8	260	2250×2000×2200	1250
BR26-BS-6-8	6-8 t/h	35-50	8	400	2250×2000×2200	1250
BR26-BS-10	10 t/h	60	11	520	2800×2000×2200	1650
BR35-BS-15	15 t/h	75	11	780	3000×2200×2200	2150
BR35-BS-20	20 t/h	80	11	945	3300×2200×2200	2350

Place of Origin:	Shanghai China (Mainland)	Brand Name:	BEYOND	Model Number:	BY-9
Type:	Processing Line,plate heat exchanger	Certification:	SOS, CE, SGS	Warranty:	1 year
temperature control:	spirax sarco steam valves	automatic:	seimens PLC and touch screen	material:	SUS304 stainless steel
